Eaton B22I-48HDG Concrete Insert - cUL Listed
Part Number: B22I-48HDG
Quick Summary
Eaton B22I-48HDG concrete insert provides a continuous concrete insert for B22 channel, delivering robust anchoring in concrete floors and mezzanines. This solution addresses the common challenge of variable load transfer and time-consuming installation associated with retrofit anchors. It carries cUL Listed certification and is built from hot-dipped galvanized 12 gauge steel, ensuring durability and long service life in demanding environments. By integrating this insert with Eaton's B-Line series, engineers can streamline fabrication, reduce field adjustments, and improve maintenance cycles. The result is reliable support for heavy-duty supports, cables, and equipment, with improved install efficiency and predictable performance in industrial facilities.
Product Information
Extended Description
B22I-48HDG Eaton: Eaton B-Line series continuous concrete insert for B22 channel, 3.1"H x 48"L x 1.6"W, Steel, 3000 load cap, Hot-dipped galvanized, 12 gauge
Product Name
Eaton B-Line series continuous concrete insert for B22 channel
Catalog Number
B22I-48HDG
UPC
781011299262
Product Length/Depth
48 in
Product Height
3.1 in
Product Width
1.6 in
Product Weight
820 lb
Certifications
cUL Listed
Finish
Hot-dipped galvanized
Material
Steel
Material gauge
12 gauge
Model
B22
Load capacity
3000 lbs
Continuous concrete inserts catalog section
Continuous concrete inserts catalog section
B-Line engineering services line card
Eaton Specification Sheet - B22I-48HDG
Feature: Continuous concrete insert for B22 channel enables seamless integration with existing B-Line framing. Benefit: Improves load transfer uniformity and reduces field modification time, lowering project risk while speeding installation on commercial and industrial sites. Application: Ideal for new builds and retrofits in factories and warehouses seeking reliable long-span anchoring. Feature: 12 gauge steel with hot-dipped galvanized finish provides corrosion resistance and durability. Benefit: Prolongs service life in harsh environments, lowers maintenance costs, and minimizes rework due to rust or degradation. Application: Suitable for exposed concrete floors and damp environments where longevity matters. Feature: 3.1 in height, 1.6 in width, and 48 in length with a 48 inch long insertion profile. Benefit: Large contact area improves stability for heavy equipment and cable support, reducing movement and misalignment. Application: Fits standard B22 channels for consistent assemblies. Feature: Load capacity rated at 3000 lbs. Benefit: Supports heavy-duty mechanical and electrical supports with predictable performance, improving safety margins and design confidence. Application: Critical where dynamic loads or seismic considerations arise. Feature: cUL Listed certification confirms electrical and safety compliance. Benefit: Streamlines compliance documentation and reduces the need for alternative approvals. Application: Preferred in North American electrical and support-system installations. Feature: Part of Eaton B-Line series ecosystem ensures compatibility and streamlined procurement. Benefit: Simplifies inventory management and accelerates design-to-install workflows. Application: Recommended for integrated projects using Eaton channel systems.
Get a Quick Quote for a Eaton B22I-48HDG
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton B22I-48HDG?
Enquire Now
FAQs
When planning installation, ensure proper alignment with existing B22 channels and confirm the concrete substrate is suitable for a 48 inch long insert. Verify that the 12 gauge steel and hot-dipped galvanizing will resist the environmental conditions, and plan for handling given the 820 lb weight. Use compatible connectors and follow Eaton installation guidelines to minimize field adjustments.
The 3000 lb load rating provides a clear upper bound for supporting equipment, cables, and structural elements. Designers should incorporate this capacity into load calculations, factoring dynamic or seismic loads where applicable. This rating enables efficient avoidance of over-design and helps ensure safety margins without unnecessary hardware redundancy.
Yes. The B22I-48HDG is designed as a continuous concrete insert for the B22 channel and is part of Eaton’s B-Line series. This compatibility supports seamless integration, reduces fabrication steps, and simplifies procurement since both the insert and channel are engineered to work together in standard Eaton configurations.
The product carries cUL Listed certification, indicating compliance with applicable safety standards for electrical and structural components in North America. This certification assists with regulatory documentation, inspection readiness, and project approval processes, reducing the need for additional third-party validation in many applications.
Plan ahead by validating alignment with the B22 channel prior to pour or embedment, and stage inserts for quick placement during concrete curing. Use hot-dipped galvanized finishes to reduce corrosion-related maintenance, and conduct pre-install checks such as height and width tolerances. Leverage Eaton’s engineering resources to optimize fixture layout and accelerate commissioning.
