Eaton B52SHA-120GLV Strut Channel - 12 Gauge, Pre-galvanized
Part Number: B52SHA-120GLV
Quick Summary
The Eaton B52SHA-120GLV Strut Back-to-Back Welded Channel is a framing solution for mounting electrical gear in industrial enclosures. Engineers often contend with installation drift, corrosion risk, and field fabrication delays, which can drive up project costs. Certifications such as CE/IEC expectations guide compliant installations, and while this specific part lists Not Applicable, its standard steel composition and pre-galvanized finish align with common industry practices for durable support structures. By design, this channel enables consistent, scalable mounting while supporting Eaton's B-Line accessory ecosystem, delivering reliable performance and reduced total cost of ownership across manufacturing and facility applications.
Product Information
Extended Description
B52SHA-120GLV Eaton: Eaton B-Line series strut back-to-back welded channel, 0.81" H x 120" L x 1.62" W, Steel, Pre-galvanized, SHA, 12 Gauge
Product Name
Eaton B-Line series strut back-to-back welded channel
Catalog Number
B52SHA-120GLV
UPC
781011845100
Product Length/Depth
12 in
Product Height
1.625 in
Product Width
1.625 in
Product Weight
2.13 lb
Certifications
Not Applicable
Channel type
B52
Hole pattern
SHA
Finish
Pre-galvanized
Material
Steel
Material gauge
12 Gauge
Channel and Combinations Catalog Section
Eaton Specification Sheet - B52SHA-120GLV
Dura-Green finish overview
Feature → Business Impact → Application: The B52SHA-120GLV uses 12 gauge steel with a pre-galvanized finish, delivering superior load-bearing capacity and corrosion resistance for long service life in harsh environments. This translates to reduced maintenance cycles and fewer rework incidents in critical electrical installations, especially within factory floors and data centers where ongoing reliability matters. Feature → Business Impact → Application: The back-to-back welded channel configuration provides structural rigidity for multi-point mounting, enabling faster assembly with SHA hole patterns and compatible fittings. This supports rapid equipment upgrades and modular expansions in control panels, racking systems, and conveyor lines, improving project timelines and change-out efficiency. Feature → Business Impact → Application: Dimensions of 0.81 in H, 12 in length, and 1.62 in W ensure compact framing without overhang, reducing space requirements in tight panels while preserving clear cable routing. Feature → Business Impact → Application: The catalog compatibility and standardization across Eaton’s B-Line range simplify procurement, streamline spares, and lower total cost of ownership by minimizing part variety. Feature → Business Impact → Application: The pre-galvanized steel construction provides predictable performance under vibration and thermal cycling typical in industrial settings, addressing both compliance and lifecycle cost concerns. By leveraging this channel, engineers can achieve consistent layouts, easier maintenance access, and scalable system designs.
Get a Quick Quote for a Eaton B52SHA-120GLV
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton B52SHA-120GLV?
Enquire Now
FAQs
Installation begins with confirming the SHA hole pattern alignment and matching hardware. Cut-to-length is allowed on the 12 inch channel, then secure with compatible nuts and bolts or Eaton mounting brackets. Use the pre-galvanized finish-compatible fasteners to maintain corrosion resistance, and ensure load distribution is balanced across the back-to-back channels to avoid bowing in high-vibration environments.
Key specs include 0.81 inch height, 12 inch length, 1.62 inch width, 12 gauge steel, pre-galvanized finish, SHA hole pattern, and catalog number B52SHA-120GLV. Weight is 2.13 pounds per channel, with UPC 781011845100. Material is steel, designed for back-to-back welded configurations in B-Line systems.
Yes. Its 12 gauge steel, pre-galvanized finish, and SHA hole pattern are optimized for mounting electrical components and support structures in panels, racking, and factory automation setups. The back-to-back welded design provides robust rigidity, making it suitable for vibration-prone environments and scalable installations in manufacturing facilities.
Certifications for this specific part are listed as Not Applicable. However, the channel uses standard pre-galvanized steel and 12 gauge construction typical of Eaton’s B-Line strut products. When used within a compliant system, it aligns with common CE/IEC expectations in practice, and Eaton provides datasheets and catalog references to support regulatory reviews.
Using the B52SHA-120GLV delivers faster installation through standardized dimensions and SHA hole compatibility, reducing field fabrication time. Its corrosion-resistant, pre-galvanized steel minimizes maintenance, while the back-to-back welded design provides rigidity for long-term reliability. The result is lower lifecycle costs, easier spares management, and scalable framing for growing electrical and mechanical installations.
