Eaton B52SHA-120HDG B-Line Strut Channel SHA
Part Number: B52SHA-120HDG
Quick Summary
Eaton B52SHA-120HDG B-Line strut channel provides rugged overhead support and equipment mounting for industrial installations. Engineers often contend with corrosion, fitment gaps, and lengthy installation when upgrading existing support structures. This back-to-back welded channel uses hot-dipped galvanized steel to resist harsh environments and integrates with standard B-Line accessories. Certifications: Not Applicable per the data, but the finish and material choices help ensure long service life and compliance with common industrial framing standards. For project cost efficiency and uptime, this solution pairs well with other strut systems for streamlined installs and predictable performance.
Product Information
Extended Description
B52SHA-120HDG Eaton: Eaton B-Line series strut back-to-back welded channel, 0.81" H x 120" L x 1.62" W, Steel, Hot-dipped galvanized, SHA, 12 Gauge
Product Name
Eaton B-Line series strut back-to-back welded channel
Catalog Number
B52SHA-120HDG
UPC
781011845117
Product Length/Depth
12 in
Product Height
1.625 in
Product Width
1.625 in
Product Weight
2.134 lb
Certifications
Not Applicable
Channel type
B52
Hole pattern
SHA
Finish
Hot-dipped galvanized
Material
Steel
Material gauge
12 Gauge
Channel and Combinations Catalog Section
Eaton Specification Sheet - B52SHA-120HDG
Dura-Green finish overview
Feature: Back-to-back welded channel design delivers higher rigidity and even load distribution across spans. Business impact: minimizes deflection under vibration and equipment weight, enabling longer, uninterrupted runs. Application: ideal for overhead support of cable trays, conduits, and mounting brackets in manufacturing facilities. Feature: 12 gauge steel with a hot-dipped galvanized finish. Business impact: provides robust corrosion resistance, reducing maintenance and replacement costs. Application: outdoor installations, damp environments, and wash-down areas where durability matters. Feature: SHA hole pattern. Business impact: supports quick, accurate alignment with standard fasteners and accessories, cutting installation time and errors. Application: cross members and beam connections where modularity is essential. Feature: 120 inch length option. Business impact: enables long spans with fewer joints, reducing parts, installation steps, and potential failure points. Application: large equipment mounts, process lines, and long framing runs in industrial settings. Feature: Broad compatibility with Eaton B-Line accessories. Business impact: simplifies design scoping, accelerates procurement, and ensures system-wide performance. Application: retrofit projects and new builds requiring scalable, compliant support structures.
Get a Quick Quote for a Eaton B52SHA-120HDG
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton B52SHA-120HDG?
Enquire Now
FAQs
The B52SHA-120HDG is designed for overhead support and equipment mounting in industrial facilities. It features a back-to-back welded channel that works with standard B-Line components, facilitating cable tray, conduit, and heavy equipment mounts along long spans with minimal joints.
The SHA hole pattern aligns with common fasteners and pre-drilled mounting points, enabling rapid positioning and fewer tuning iterations during assembly. This reduces on-site labor, accelerates project timelines, and minimizes misalignment risks for critical support structures.
Yes. The B52SHA-120HDG uses hot-dipped galvanized steel, which offers enhanced corrosion resistance suitable for outdoor, humid, or wash-down areas. This extends service life and lowers maintenance costs in challenging industrial settings.
Per the provided data, certifications are listed as Not Applicable. Nevertheless, the component is built from galvanized steel and is designed to integrate with standard B-Line accessories that meet typical industrial framing standards.
The channel enables longer spans with fewer joints, reducing parts and installation steps. Its compatibility with a wide range of accessories simplifies design changes, lowers procurement complexity, and improves uptime by delivering a robust, corrosion-resistant mounting solution with predictable performance.
