Eaton B767-42ZN B-Line joiner - UL Listed
Part Number: B767-42ZN
Quick Summary
The Eaton B767-42ZN B-Line joiner is a steel 90° elbow connector for B-Line strut systems. Manufacturers and integrators often struggle with fast, secure right-angle connections that stay aligned during vibration and heat. UL Listed certification ensures electrical safety compliance in commercial and industrial installations, while its 12-gauge steel construction provides durable performance in demanding environments. By combining quick cam-screw installation with a compact profile, this joiner reduces installation time and minimizes inventory complexity. In short, it delivers predictable fit, robust support for loads, and better lifecycle cost when paired with Eaton B-Line accessories. Its UL listing and compatibility with standard fitment holes simplify audits and maintenance planning.
Product Information
Extended Description
B767-42ZN Eaton: Eaton B-Line series joiner, 1" H x 2.31" L x 1.62" W, Steel, 12 gauge
Product Name
Eaton B-Line series joiner
Catalog Number
B767-42ZN
UPC
781011574567
Product Length/Depth
2.31 in
Product Height
1 in
Product Width
1.62 in
Product Weight
0.27 lb
Certifications
UL Listed
Special features
Includes 2 cam screws
Type
90° Elbow strut joiner
Material
Steel
Material gauge
12 gauge
Feature: 90° elbow strut joiner design. Business Impact: Enables precise, right-angle connections with minimal misalignment, reducing rework and field errors. Application: Ideal for creating corner sections in B-Line strut systems, panels, and enclosures, improving installation reliability. Feature: Compact footprint at 1 in H x 2.31 in L x 1.62 in W. Business Impact: Maximizes usable space in crowded panels and mounting areas, enabling denser layouts and cleaner wire management. Application: Suitable for high-density electrical racks and equipment housings where space is at a premium. Feature: 12-gauge steel construction (0.27 lb weight). Business Impact: Delivers robust strength with lightweight handling, reducing labor and tool fatigue during install. Application: Harsh industrial environments where chassis rigidity and ease of handling matter. Feature: UL Listed certification. Business Impact: Provides regulatory compliance and risk mitigation for electrical installations, supporting audits and safety programs. Application: Required or preferred for commercial and industrial electrical projects. Feature: Includes 2 cam screws for fast installation. Business Impact: Speeds assembly, lowers labor cost, and minimizes field alignment adjustments. Application: On-site installations where time-to-energize is critical. Feature: B-Line system compatibility. Business Impact: Reduces part variety and stocking needs, simplifying procurement and maintenance planning. Application: Integrated into Eaton B-Line accessories suites for consistent performance and fit.
Get a Quick Quote for a Eaton B767-42ZN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton B767-42ZN?
Enquire Now
FAQs
The B767-42ZN is a 90° elbow joiner designed for Eaton's B-Line strut systems. It inserts between standard B-Line members to form right-angle corners, aligning with the system's holes and holes spacing. It includes two cam screws for fast, secure fastening, enabling quick assembly without special tools. Its 12 gauge steel construction provides dependable rigidity for rack enclosures and mounting frames.
Key specs are 1 in height, 2.31 in length, 1.62 in width, 12 gauge steel, and a weight of 0.27 lb. This combination delivers a robust, rigid corner connection suitable for standard B-Line loads while remaining manageable during field installation. The UL Listed certification adds confidence in electrical safety and system reliability under typical industrial loads.
Yes, the 12 gauge steel construction provides core durability needed for moderate vibration environments common in industrial settings. The cam screw fastening ensures a tight, repeatable clamping force, reducing loosening over time. For extreme vibration or outdoor exposure, consider supplemental bracing or protective housings as part of a broader mounting strategy.
The B767-42ZN is UL Listed, signaling compliance with electrical safety standards for commercial and industrial installations. This certification supports safety audits, code compliance, and regulatory acceptance in most markets. While UL Listed is the primary certification listed here, it aligns with Eaton’s standard for B-Line accessories and can simplify procurement and approval workflows.
Fast cam-screw installation minimizes on-site assembly steps, reducing labor hours per joint and speeding energization of systems. The compact footprint and compatibility with existing B-Line components simplify spares management, inventory planning, and audits. Overall, the product helps lower total cost of ownership by improving install velocity and long-term reliability.
