Eaton B768-12ZN Tee Strut Joiner - UL Listed
Part Number: B768-12ZN
Quick Summary
Eaton B768-12ZN Tee Strut joiner connects B-Line strut runs to form stable tee junctions in electrical support systems. Designers and installers often contend with misalignment and time-consuming field fabrication when joining sections. UL Listed certification supports electrical-safety compliance in industrial environments, helping you meet rigorous safety requirements. This joiner delivers reliable performance, compatibility with Tee strut systems, and faster installation, translating to reduced field labor and lower total cost for panel assemblies and support frames.
Product Information
Extended Description
B768-12ZN Eaton: Eaton B-Line series joiner, 2.43" H x 4.5" L x 1.62" W, Steel, 12 gauge, Tee strut joiner
Product Name
Eaton B-Line series joiner
Catalog Number
B768-12ZN
UPC
781011574611
Product Length/Depth
4.5 in
Product Height
2.43 in
Product Width
1.62 in
Product Weight
1.12 lb
Certifications
UL Listed
Special features
Includes 3 cam screws
Type
Tee strut joiner
Material
Steel
Material gauge
12 gauge
Feature: Steel construction with 12 gauge material provides robust mechanical strength. Business Impact: Enhanced rigidity reduces flex under load, improving long-term reliability in assemblies for electrical enclosures. Application: Perfect for fixed, high-load B-Line runs in automation facilities. Feature: 4.5 in length, 2.43 in height, 1.62 in width, and 1.12 lb weight offer a compact yet strong profile. Business Impact: Easier handling and precise fit in tight spaces, enabling faster layout planning and lower installation time. Application: Data centers and panel rooms where space is at a premium. Feature: Includes 3 cam screws for quick, tool-efficient attachment. Business Impact: Minimizes on-site hardware searches and accelerates first-pass installation. Application: Quick-assembly Tee strut joins in complex rack configurations. Feature: UL Listed certification ensures adherence to electrical safety standards. Business Impact: Reduces compliance risk and supports audit readiness. Application: Industrial automation and panel assembly environments. Feature: Compatibility with B-Line series Tee strut systems ensures seamless integration. Business Impact: Streamlines procurement and reduces rework due to fit issues. Application: Standard B-Line installations across new builds and upgrades.
Get a Quick Quote for a Eaton B768-12ZN
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton B768-12ZN?
Enquire Now
FAQs
To install, align the joiner with the Tee intersection of the B-Line strut, insert the included cam screws, and tighten until the joint remains rigid. The 12 gauge steel provides steady support, while the three cam screws minimize hardware handling. This setup suits panel assemblies and overhead supports in automation facilities.
Performance is driven by the 12 gauge steel construction, overall dimensions (4.5 in length, 2.43 in height, 1.62 in width), and weight (1.12 lb). The UL Listed certification assures safety compliance in electrical environments, while the included cam screws facilitate rapid, repeatable installations.
Yes. The B768-12ZN is designed for Tee strut junctions in B-Line systems, commonly used in electrical enclosures, cable tray supports, and industrial automation frames. Its robust steel construction and precise dimensions ensure dependable fits, alignment, and load transfer in demanding environments.
The joiner is UL Listed, indicating compliance with recognized electrical safety standards. This certification helps reduce compliance risk during audits and supports safer operation in industrial installations, light to heavy automation, and panel assembly projects.
Maintenance is minimal: solid steel construction resists wear, and the included three cam screws simplify rework or future changes. ROI comes from faster installs, reduced field labor, and reliable joints that limit rework, especially valuable in high-mix automation environments and retrofit projects.
