Eaton BAB2040HI Thermal Magnetic Circuit Breaker - 10 kAIC
Part Number: BAB2040HI
Quick Summary
The Eaton BAB2040HI thermal magnetic circuit breaker protects 240 V three-phase power distribution panels. Its bolt-on mounting and Quicklag operation reduce installation time and nuisance trips in demanding industrial enclosures. It is UL Listed and CSA Certified with HACR rating, providing reliable protection for HVAC equipment and general panel loads while meeting essential safety standards. Designed for distribution panels at 240 V (three-phase, four-wire maximum), this unit offers a compact footprint without sacrificing interrupt capacity, supporting up to 10 kAIC. For engineers and procurement professionals, the combination of robust protection, serviceability, and Eaton compatibility translates into lower lifecycle costs and dependable uptime.
Product Information
Extended Description
BAB2040HI Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Bolt-on mounting,40 A,10 kAIC,Two-pole,240 V,Non-Interchangeable,Q7,BAB,Ring or spade lug terminals
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB2040HI
UPC
782114312728
Product Length/Depth
2.563 in
Product Height
3 in
Product Width
2 in
Product Weight
0.6 lb
Warranty
1 year
Compliances
HACR Rated
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Number of poles
Two-pole
Number of wires
4
Terminals
Ring or spade lug
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
40 A
Interrupt rating
10 kAIC
Phase
Three-phase
Trip Type
T196
Voltage rating
240 V - 240 V
Quantity
7
Special features
Bolt-on mounting
Used with
Distribution panels 240 V (Three-phase, four-wire maximum)
Circuit Protection, Miniature Circuit Breakers and Supplementary Protectors, Volume 4, Tab 1
Circuit Breakers Explained
Eaton Specification Sheet - BAB2040HI
