Eaton BAB3020HS ThermalMagnetic Circuit Breaker - UL Listed
Part Number: BAB3020HS
Quick Summary
The Eaton BAB3020HS thermal magnetic circuit breaker protects industrial panels from overloads and short circuits. Engineers often contend with nuisance trips, slow fault isolation, and costly downtime during panel servicing. UL Listed and CSA Certified devices with HACR rating help ensure compliance in motor control and equipment enclosures. By standardizing on a 20 A, three‑pole breaker with bolt‑on mounting, you gain predictable protection and faster installation. This unit’s 240 V rating and 10 kAIC interrupt capacity support reliable performance in demanding automation lines. In projects where safety, code compliance, and uptime matter, the BAB3020HS improves maintenance planning and total cost of ownership.
Product Information
Extended Description
BAB3020HS Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,20 A,10 kAIC,Three-pole,240 V,Non-Interchangeable,Q32,BAB,24/48 Vdc Shunt trip
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3020HS
UPC
786679509647
Product Length/Depth
4 in
Product Height
3.5 in
Product Width
3.7 in
Product Weight
1.25 lb
Warranty
1 year
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
20 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mounting
Feature: 20 A amperage rating paired with a 10 kAIC interrupt capacity provides robust protection against both overloads and short circuits, reducing the likelihood of costly equipment damage and unplanned downtime. Business impact: Fewer nuisance trips and faster fault isolation translate to higher line uptime and safer operation in manufacturing environments. Application: Suitable for three‑phase machine controls and automation panels where reliable protection is essential. Feature: Three‑pole, bolt‑on mounting with a compact 4 in x 3.5 in x 3.7 in footprint simplifies retrofit and new panel layouts. Business impact: Easier installations, reduced assembly time, and stable mechanical contact improve long‑term reliability in control cabinets. Application: Ideal for retrofit projects and new builds in conveyor systems, packaging lines, and robotics cells. Feature: UL Listed, CSA Certified, and HACR rated certification combination ensures regulatory compliance and safe operation in motor circuits. Business impact: Streamlined approvals, risk mitigation for electrical inspections, and better insurance alignment. Application: Widely used in industrial motor control centers and OEM equipment. Feature: Optional 24/48 Vdc shunt trip integrates with centralized safety interlocks and remote shutdown schemes. Business impact: Enhanced safety coordination and controlled shutdowns during maintenance. Application: Automation and process lines requiring remote disconnection. Feature: Non‑interchangeable trip type prevents incorrect replacements and preserves protection coordination. Business impact: Reduces maintenance errors, extends service life, and simplifies spares planning. Application: Critical control panels in high‑demand environments. Additional notes: Quicklag industrial thermal‑magnetic technology and HACR‑rated performance align with industry standards for dependable, code‑compliant protection across diverse manufacturing contexts.
Get a Quick Quote for a Eaton BAB3020HS
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BAB3020HS?
Enquire Now
FAQs
The BAB3020HS is designed for standard industrial control panels and fits a three‑pole, bolt‑on configuration with a footprint of 4 in by 3.5 in by 3.7 in. It is well suited for retrofit projects and new installations in automated lines, conveyors, and machine controls requiring secure mechanical attachment and robust protection.
It features a 20 A amperage rating, 240 V voltage rating, and 10 kAIC interrupt capacity with a non-interchangeable trip type. This combination supports reliable protection for three-phase systems and ensures predictable response to overloads and short circuits in industrial equipment.
Yes. With HACR rating and UL Listed CSA Certified status, it is appropriate for motor control circuits and automation equipment up to 20 A at 240 V. When coordinating with overload devices, it helps protect motors and drives while maintaining panel safety and regulatory compliance.
The device is UL Listed and CSA Certified, with HACR rating. HACR stands for Heating, Air Conditioning, and Refrigeration, indicating suitability for motor load circuits. This combination supports compliance in many industrial settings and reduces the need for additional motor protection coordination in standard control panels.
Bolt-on mounting simplifies installation, reducing labor time and improving mechanical reliability. The non-interchangeable trip type minimizes incorrect replacements, while the 10 kAIC interrupt capacity provides strong fault protection. Optional 24/48 Vdc shunt trip adds remote shutdown capability, enhancing safety and uptime in automated production lines.
