Eaton BAB3035HS Thermal Magnetic Circuit Breaker - HACR rated
Part Number: BAB3035HS
Quick Summary
Eaton BAB3035HS thermal magnetic circuit breaker protects industrial power panels by interrupting fault currents. It helps prevent nuisance trips and unplanned downtime in demanding environments. UL Listed and CSA Certified with HACR rating and 240 V operation ensure regulatory compliance and safe operation. Bolt-on mounting, Quicklag performance, and a 35 A rating deliver reliable protection while enabling fast retrofits and simplified panel upgrades for control enclosures and machinery feeds.
Product Information
Extended Description
BAB3035HS Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Bolt-on mounting, 50° C Calibration,35 A,10 kAIC,Three-pole,240 V,Non-Interchangeable,Q32,BAB
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3035HS
UPC
786679378021
Product Length/Depth
3.8 in
Product Height
4.9 in
Product Width
3.2 in
Product Weight
0.85 lb
Warranty
1 year
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
35 A
Interrupt rating
10 kAIC
Trip Type
Non-interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Shunt trip
120-240V
Special features
Bolt-on mounting50° C Calibration
Three-pole, Quicklag industrial thermal-magnetic design delivers robust overload and short-circuit protection, reducing equipment damage and downtime in harsh environments. This translates to safer start-ups and fewer trips during start-up surges, improving line efficiency in manufacturing and processing facilities. Bolt-on mounting enables rapid installation and straightforward retrofits into standard panels, cutting commissioning time and service costs while maintaining secure enclosure integration. With a 35 A rating and 10 kAIC interrupt capacity, it supports heavier feeders and high inrush loads, providing predictable protection for pumps, conveyors, and controllers. Calibrated for 50°C operation, it maintains accurate trip settings in warm plant spaces, while HACR rating and UL/CSA certifications assure ongoing compliance and safety. The optional shunt-trip capability (120–240 V) offers remote trip control for safer machine safeguards and lockout-tagout workflows.
Get a Quick Quote for a Eaton BAB3035HS
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BAB3035HS?
Enquire Now
FAQs
The BAB3035HS uses bolt-on mounting, designed for quick, secure installation in standard industrial enclosures. Its compact 3.8 in depth, 3.2 in width, and 4.9 in height fit common panel cutouts, enabling straightforward retrofits without extensive enclosure modification.
The BAB3035HS provides a 35 A continuous amperage rating with a 10 kAIC interrupt capacity, offering strong fault-current clearance for demanding loads while limiting nuisance trips in normal operation.
Yes. The device is rated for 240 V and configured as a three-pole breaker, making it suitable for three-phase protection in industrial panels and machinery feeders.
This breaker is UL Listed and CSA Certified and HACR rated, with 50°C calibration, supporting compliance in HVAC, electrical, and process-control applications. Shunt-trip options are available for remote trip control.
Plan for bolt-on mounting to minimize wiring changes, verify enclosure compatibility, and reference the Eaton specification sheet for exact wiring diagrams. Use the 50°C calibration and HACR rating guidelines to maintain proper trip performance and stay aligned with safety standards.
