Eaton BAB3060N Thermal Magnetic Circuit Breaker - UL Listed
Part Number: BAB3060N
Quick Summary
The Eaton BAB3060N thermal magnetic circuit breaker provides reliable overcurrent protection for industrial control panels. Engineers often face installation delays or nuisance trips in demanding environments, which this unit helps mitigate with bolt-on mounting and robust trip characteristics. UL Listed and CSA Certified, HACR rated, the BAB3060N delivers safety and regulatory confidence for mid- to high-volume electrical installations. By combining a compact footprint with 60 A at 240 V and a 10 kAIC interrupt rating, it supports scalable protection strategies while simplifying procurement and stocking for maintenance teams and OEM projects.
Product Information
Extended Description
BAB3060N Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Bolt-on mounting, 400 Hz calibrated,70 A,10 kAIC,Three-pole,240 V,Non-Interchangeable,Q32,BAB
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3060N
UPC
786679660140
Product Length/Depth
3.8 in
Product Height
4.9 in
Product Width
3.2 in
Product Weight
0.9 lb
Warranty
1 year
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
60 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mountingNon-automatic
Feature → Business Impact → Application: Bolt-on mounting enables fast, secure installation with minimal panel modification, reducing commissioning time and labor costs in new builds or refurbishments. Application: Industrial control panels and machine safety circuits where quick, reliable protection is required. Feature → Business Impact → Application: Three-pole configuration provides coordinated protection across three phases, improving system reliability in three-phase networks common in manufacturing environments. Application: Battery of feeders and distribution blocks in automation lines where balanced protection is essential. Feature → Business Impact → Application: 60 A, 240 V rating and 10 kAIC interrupt capability reduce the risk of damaging faults, safeguarding expensive motors and drives while complying with electrical standards. Application: Main and branch-circuit protection in panel boards and equipment racks. Feature → Business Impact → Application: HACR rated and UL Listed CSA Certified certifications simplify regulatory approvals, facility audits, and insurance compliance. Application: Industrial facilities requiring recognized safety marks for control circuits and HVAC/electrical installations. Feature → Business Impact → Application: Compact 3.8 in x 3.2 in x 4.9 in footprint and 0.9 lb weight support space-saving layouts and easier replacement in crowded panels. Application: Retrofit projects and OEM assemblies where space is at a premium and downtimes must be minimized.
Get a Quick Quote for a Eaton BAB3060N
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BAB3060N?
Enquire Now
FAQs
The BAB3060N uses bolt-on mounting for secure, fast installation. Its three-pole configuration fits common panel cutouts, and the bolt-on design allows straightforward field mounting without special tools. Ensure your panel supports 240 V circuits and provides adequate clearance for heat dissipation.
This model is rated 60 A at 240 V with a 10 kAIC interrupt rating. It is a non-interchangeable trip device and carries UL Listed and CSA Certified marks, plus HACR rating, suitable for controlled industrial applications and safety-compliant installations.
Yes. The BAB3060N is designed for 240 V three-pole service with calibration suitable for 400 Hz systems where applicable. It provides reliable protection for industrial controls and machinery, reducing nuisance trips while maintaining system performance in high-frequency environments.
The BAB3060N carries UL Listed and CSA Certified marks and is HACR rated. These certifications support regulatory acceptance, simplify audits and warranty processes, and provide confidence for safety compliance in industrial facilities and OEM programs.
Regularly inspect terminals and mounting hardware, verify torque per catalog guidance, and monitor heat generation during operation. Maintain clean terminations and replace worn bolts or springs as needed. Adhering to routine inspections helps prevent loose connections and unplanned outages, extending lifecycle and reducing downtime in production environments.
