Eaton BAB3070HS1 Thermal-Magnetic Breaker - HACR
Part Number: BAB3070HS1
Quick Summary
The Eaton BAB3070HS1 thermal magnetic circuit breaker protects three‑phase power distributions with reliable overload protection. Engineers often face nuisance trips or mis-tuned protection when coordinating DC shunt-trip options with automation systems. Certified CSA and UL Listed and HACR rated, it meets essential safety standards for industrial control panels. Its bolt-on mounting, 3-pole construction, and 240 V rating support fast, compliant installations in demanding environments. With a 70 A rating and 10 kAIC interrupt capacity, it provides scalable protection for motor feeders and process lines. This combination reduces downtime and simplifies compliance reporting by aligning with industry standards, while the 24/48 V DC shunt trip enhances safety in automated systems.
Product Information
Extended Description
BAB3070HS1 Eaton: Quicklag Industrial Thermal-Magnetic Circuit Breaker, Three-pole, 24,48V/dc shunt trip, 70A, 10 kAIC, 240V, Non-Interchangeable
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3070HS1
UPC
786679378465
Product Length/Depth
5 in
Product Height
1 in
Product Width
3 in
Product Weight
0.5 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Thermal magnetic circuit breakers
Amperage Rating
70A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
24,48V/dc shunt trip
Three-pole thermal-magnetic design with a 70 A rating and 10 kAIC interrupt capacity provides reliable overload protection for three‑phase circuits. This delivers dependable uptime and reduces motor wear, making it ideal for motor feeders in industrial panels. Application: suitable for manufacturing environments where rapid, predictable trips are essential. DC shunt trip capability at 24/48 V DC enables remote or safety interlock shutdown in automation lines. This feature minimizes risk during maintenance or emergency events, improving worker safety and process resilience. Application: useful for conveyors, presses, and automated lines requiring quick disconnection. Bolt-on mounting supports fast installation and straightforward retrofits. Business impact: reduces field labor costs and panel downtime while enabling seamless integration with standard enclosures. Application: retrofit projects and new builds in control cabinets. HACR rated with CSA UL listing provides NEC-aligned safety and reliability. Business impact: simplifies compliance and reduces approver queries during audits. Application: HVAC control circuits and building automation panels in commercial and industrial settings. Compact footprint (5 in depth x 3 in width x 1 in height) and 0.5 lb weight optimize panel space. Business impact: enables denser, more organized control panels and easier handling during installation. Application: space-constrained electrical cabinets and automation enclosures. Rated for 240 V operation with 70 A protection and 10 kAIC interrupt capacity, it delivers robust protection for general purpose machinery. Business impact: supports scalable protection across machinery, pumps, and process lines. Application: three‑phase machinery feeders in manufacturing facilities.
