Eaton BAB3090HS Circuit Breaker - 10 kAIC, UL Listed
Part Number: BAB3090HS
Quick Summary
Eaton BAB3090HS circuit breaker provides reliable overcurrent protection for industrial control panels and motor drives. This solution reduces nuisance trips and unplanned downtime in demanding environments. CSA Certified and UL Listed with HACR ratings help meet regulatory and HVAC application requirements, reinforcing safety and compliance. The three-pole design with bolt-on mounting simplifies retrofits and new installations, while the 90 A rating and 10 kAIC interrupt capacity support motor protection and short-circuit resilience. In short, it combines rugged protection with installation flexibility to maximize uptime and project certainty. Engineers value its compact footprint and clear labeling, which streamline documentation for compliance audits and spare-part planning across multiple sites.
Product Information
Extended Description
BAB3090HS Eaton: Eaton Quicklag Industrial Thermal-Magnetic Circuit Breaker, Three-pole, 120V, 208V, 240V shunt trip, 90A, 10 kAIC, 240V, Non-Interchangeable, Bolt-on mounting
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3090HS
UPC
786679509715
Product Length/Depth
4.1 in
Product Height
3.2 in
Product Width
3.7 in
Product Weight
1.2 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
90 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mounting
The BAB3090HS uses a three-pole design with bolt-on mounting to deliver dependable three‑phase protection for large motors, pumps, and control panels. This configuration reduces mis-coordination across three-phase circuits and accelerates panel assembly, supporting faster commissioning and easier future upgrades in motor control centers and machine panels. The thermal-magnetic trip combines overload protection with rapid magnetic response for short-circuit events, which minimizes damage, reduces downtime, and improves safety during high-inrush starting or fault conditions. With a 10 kAIC interrupt rating at 240 V, the breaker withstands high fault currents, enabling compliant upstream protection and safer, more reliable power distribution for industrial equipment. Optional shunt-trip capability enables remote tripping for enhanced safety during maintenance or emergency shutdowns, while UL Listed and CSA Certified status helps satisfy regulatory requirements. The unit’s HACR rating confirms suitability for HVAC-related equipment, and its compact bolt-on design simplifies retrofits and new installations in confined spaces. Finally, a 1-year warranty and lightweight profile reduce lifecycle costs and simplify inventory management for maintenance teams.
