Eaton BAB3090HV Circuit Breaker - CSA UL Listed for Panels
Part Number: BAB3090HV
Quick Summary
The Eaton BAB3090HV thermal-magnetic circuit breaker protects three-phase industrial power circuits from overloads. In modern plants, nuisance trips and inconsistent calibration can cause costly downtime; this device offers precise 50°C calibration and a robust 90 A rating to minimize that risk. With CSA Certified and UL Listed markings and HACR rating, it meets North American electrical codes and motor/HVAC protection needs. Bolt-on mounting and a compact three-pole design simplify installation and future expansions, delivering reliable protection with straightforward maintenance. Designed for harsh environments and frequent service, it supports scalable protection strategies for panel boards and motor drives.
Product Information
Extended Description
BAB3090HV Eaton: Quicklag Industrial Thermal-Magnetic Circuit Breaker, Three-pole, 50° C Calibration, 90A, 10 kAIC, 240V, Bolt-on mounting
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3090HV
UPC
786679304693
Product Length/Depth
3.8 in
Product Height
4.7 in
Product Width
3.2 in
Product Weight
0.95 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
90 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mounting50° C Calibration
Three-pole, bolt-on thermal-magnetic design delivers robust overcurrent protection; this reduces nuisance trips and guards motors and feeders in demanding environments. It supports quick field retrofits in panel boards and motor control centers, speeding installation and reducing downtime. The 90 A, 240 V rating paired with a 10 kAIC interrupt capacity ensures reliable fault current interruption for medium-to large-scale industrial systems, protecting downstream equipment and reducing repair costs. A 50°C calibration feature maintains consistent trip characteristics across elevated ambient temperatures, improving predictability in hot plant areas and minimizing unexpected shutdowns. Certifications including CSA Certified and UL Listed, plus HACR rating, provide regulatory confidence for HVAC and motor loads and help streamline audit processes. Bolt-on mounting and a compact footprint support scalable protection while simplifying future expansions and maintenance.
Get a Quick Quote for a Eaton BAB3090HV
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BAB3090HV?
Enquire Now
FAQs
The BAB3090HV uses bolt-on mounting and a three-pole configuration, simplifying field installation. Ensure proper wiring per Eaton datasheet, observe rated voltage 240 V, and secure the breaker to the panel frame to maintain vibration resistance and reliable trip performance.
It is CSA Certified and UL Listed, with HACR rating. These certifications confirm compliance with North American electrical codes and suitability for HVAC and motor protection, helping with regulatory audits and customer acceptance.
The BAB3090HV offers a 10 kAIC interrupt rating, enabling it to safely interrupt high fault currents typical in industrial feeders and motor circuits, reducing the risk of equipment damage and improving system resilience.
Yes. Its three-pole design, 90 A rating, and HACR compatibility make it well-suited for motor control centers, panel boards, and other industrial power distribution applications where reliable overload protection is required.
Plan for proper clearance and wiring access, ensure secure mounting to withstand vibrations, and follow the manufacturer’s torque specifications. Bolt-on mounting facilitates faster replacements and easier upgrades in evolving control panels.
