Eaton BAB3100H Thermal Magnetic Circuit Breaker - UL Listed
Part Number: BAB3100H
Quick Summary
Eaton BAB3100H thermal magnetic circuit breaker protects industrial control circuits with fast, reliable overcurrent protection. For engineers and procurement teams, nuisance trips and retrofit panel fit challenges can drive downtime and operating costs. CSA Certified and UL Listed approvals, plus a HACR rating for HVAC equipment, support compliance across diverse manufacturing environments. With bolt-on mounting and a 100 A three-pole design, it saves panel space and simplifies installation, while 240/415 V coverage fits common industrial power distributions.
Product Information
Extended Description
BAB3100H Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Bolt-on mounting,100 A,6 kAIC,Three-pole,240/415 V,Non-Interchangeable,Q32,BAB
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3100H
UPC
786679304006
Product Length/Depth
2.9 in
Product Height
2.9 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
100 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mounting
Feature: Quicklag industrial thermal-magnetic design delivers fast, precise tripping and stable protection. Business Impact: Reduces nuisance trips and minimizes unplanned downtime on motor loads. Application: Ideal for industrial control panels and distribution boards where reliability matters. Feature: Bolt-on mounting simplifies installation and reduces field hardware for faster retrofits. Business Impact: Cuts installation time and labor costs while improving serviceability. Application: Retrofit projects and new panel builds in production lines. Feature: Three-pole configuration at 100 A with a 10 kAIC interrupt rating. Business Impact: Robust short-circuit protection for three-phase loads, improving equipment safety and uptime. Application: Large motor feeders and heavy loads in manufacturing environments. Feature: Non-Interchangeable trip type ensures consistent protection characteristics. Business Impact: Prevents mis-sizing during replacements, preserving panel protection integrity. Application: Critical power distribution and HVAC/industrial automation installations. Feature: HACR rated with CSA Certified and UL Listed certifications. Business Impact: Facilitates regulatory compliance and safe operation in HVAC and general industrial applications. Application: Panels requiring certified protection and HVAC integration. Feature: Compact footprint (2.9 in x 3 in x 2.9 in) and weight of 1 lb with 100 A rating. Business Impact: Space-saving design enables denser panel layouts and easier handling during installation. Application: Space-constrained control cabinets and upgrade projects.
Get a Quick Quote for a Eaton BAB3100H
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BAB3100H?
Enquire Now
FAQs
The BAB3100H uses bolt-on mounting, designed for straightforward installation in new panels or retrofits. Its compact 3-pole footprint and standard bolt-on approach simplify upgrading existing systems, reducing installation time and potential wiring errors while maintaining secure mechanical attachment in harsh industrial environments.
Key ratings include a 100 A amperage rating, 10 kAIC interrupt capacity, and a voltage range of 240 V to 240 V. It is a three-pole device with non-interchangeable trip, HACR rating, and certified by CSA with UL listing, making it suitable for demanding three-phase applications.
Yes. The BAB3100H is HACR rated, which aligns with HVAC equipment protection standards, and its 10 kAIC interrupt capacity supports motor start-up transients. Its three-pole, 240/415 V design is common in motor control centers and air handling units within industrial facilities.
The BAB3100H is CSA Certified and UL Listed, signaling compliance with recognized safety standards for electrical protection devices. These certifications simplify procurement for regulated environments and help ensure safe integration into industrial control panels and HVAC systems.
With a 1-year warranty and a robust thermal-magnetic mechanism, the BAB3100H offers reliable protection with minimal maintenance. Its non-interchangeable trip and bolt-on design reduce mis-wiring risk and downtime during replacements, contributing to lower total cost of ownership in demanding production environments.
