Eaton BAB3100HE Circuit Breaker - CSA Certified UL Listed
Part Number: BAB3100HE
Quick Summary
The Eaton BAB3100HE is a 100 A thermal magnetic circuit breaker designed to protect industrial power panels from overloads and short circuits. In practice, engineers often contend with nuisance trips and compatibility gaps when wiring across 240/415 V systems, which can disrupt production and extend commissioning times. This device is HACR rated and CSA Certified UL Listed, delivering dependable protection while meeting essential safety and regulatory requirements in harsh industrial environments. With bolt-on mounting and a true three-pole design, it streamlines installation, reduces panel space, and supports reliable motor protection and overall electrical safety across demanding applications.
Product Information
Extended Description
BAB3100HE Eaton: Quicklag Industrial Thermal-Magnetic Circuit Breaker, 100A, BAB type, 6 kAIC, Bolt-on mounting, Three-pole, Non-Interchangeable, 240/415V
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3100HE
UPC
786679378625
Product Length/Depth
5 in
Product Height
1 in
Product Width
3 in
Product Weight
0.5 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Thermal magnetic circuit breakers
Amperage Rating
100 A
Interrupt rating
6 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240/415V
Quantity
32
The 100 A amperage rating paired with a 6 kAIC interrupt capability provides robust protection for high-current circuits while maintaining selectivity to minimize unintended outages. This translates to measurable uptime improvements in manufacturing lines and packaging systems, especially where heavy start-up loads are common. The BAB3100HE operates at 240/415 V, making it suitable for typical three-phase power layouts in control panels, motor control centers, and distribution boards, and it helps engineers meet code requirements without oversizing components. Bolt-on mounting simplifies field installation, reducing labor cost and the potential for wiring errors during retrofit projects. The three-pole configuration supports true three-phase protection, improving phase balance and safeguarding motors and drives from transient faults. Certified and HACR rated, it strengthens compliance while limiting lifecycle risk and maintenance downtime. Weighing just 0.5 lb with compact dimensions (5 in length, 3 in width, 1 in height), it fits tight panel spaces and enables faster upgrades in retrofit projects. In practice, this means lower total cost of ownership, easier spare-part planning, and more predictable protection in critical lines. Compatibility with common Eaton accessories and standard mounting patterns also accelerates installation across a wide range of panels and machines.
Get a Quick Quote for a Eaton BAB3100HE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BAB3100HE?
Enquire Now
FAQs
Yes. The BAB3100HE uses a bolt-on mounting method designed for easy retrofit into existing three-pole panels. Its bolt-on format reduces installation time, aligns with standard DIN rail and electrical enclosure practices, and minimizes field wiring complexity while maintaining secure mechanical integrity.
The device is a 100 A amperage rating circuit breaker with a 6 kAIC interrupt rating, suitable for 240/415 V three-phase systems. Its non-interchangeable trip type ensures consistent protection characteristics, and its HACR rating supports motor and compressor protection in compliant installations.
Absolutely. The three-pole configuration and robust interrupt rating make the BAB3100HE ideal for motor control centers, control panels, and distribution boards in industrial settings. Its compact bolt-on design helps with dense panel layouts while providing reliable overload and short-circuit protection.
It is CSA Certified and UL Listed, and HACR rated, which supports compliance with common safety and electrical codes for industrial installations. These certifications help reduce procurement risk and streamline auditor reviews during project commissioning.
The BAB3100HE carries a 1-year warranty, reflecting Eaton’s confidence in long-term reliability. Routine maintenance is minimal, with emphasis on proper torque during bolt-on installation and periodic inspections for secure mounting. Its durable design contributes to lower downtime costs and predictable lifecycle economics in high-demand applications.
