Eaton BAB3100HS Thermal Magnetic Breaker - CSA UL Listed
Part Number: BAB3100HS
Quick Summary
The Eaton BAB3100HS thermal magnetic circuit breaker protects industrial electrical feeders in control panels. This design helps prevent nuisance trips and mis-sizing in demanding automation environments. It carries CSA Certified and UL Listed marks and is HACR rated for broader compatibility. For panel builders and integrators, bolt-on mounting, three-pole configuration, and 240 V operation translate to faster installations and reliable protection. Built-in shunt trip options (24/48 Vdc) offer integration flexibility for remote signaling. With a compact 4 x 3.3 x 3.7 inch footprint and a 1.25 lb weight, it fits tight control panels while delivering robust protection. Engineers value the 1-year warranty and CSA UL certifications for peace of mind during audits and compliance reviews.
Product Information
Extended Description
BAB3100HS Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,100 A,10 kAIC,Three-pole,240 V,Non-Interchangeable,Q32,BAB,24/48 Vdc Shunt trip
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3100HS
UPC
786679509722
Product Length/Depth
4 in
Product Height
3.3 in
Product Width
3.7 in
Product Weight
1.25 lb
Warranty
1 year
Certifications
CSA Certified UL Listed
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
100 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mounting
The BAB3100HS uses a combined thermal-magnetic trip mechanism to deliver coordinated overload and short-circuit protection, reducing nuisance trips and protecting motor loads in automation panels. This translates to lower downtime and longer equipment life for conveyors, presses, and CNC machines. It is rated at 100 A with a 10 kAIC interrupt rating, enabling rapid fault clearance in high-current scenarios and enhancing overall process uptime. Bolt-on mounting and a compact footprint simplify installation in crowded control cabinets, reducing labor time and easing retrofits in existing enclosures. A 24/48 Vdc shunt trip option adds safety flexibility, allowing remote trip signaling for safety interlocks and emergency-stop circuits without compromising protection. The non-interchangeable trip design minimizes the risk of incorrect replacements, while HACR rating and CSA UL certifications support HVAC or general electrical compliance in industrial facilities. A 1-year warranty and robust Eaton support network further reduce lifecycle costs by simplifying maintenance planning and parts availability.
