Eaton BAB3100HS1 Thermal Magnetic Circuit Breaker - UL Listed
Part Number: BAB3100HS1
Quick Summary
The Eaton BAB3100HS1 thermal magnetic circuit breaker protects electrical circuits in industrial panels by interrupting fault currents. Many designers contend with nuisance trips from transient inrush and the demand for reliable 24,48V DC shunt-trip protection. This unit is UL Listed and CSA Certified and HACR rated, aligning with safety standards and panel-building requirements. It supports a three-pole, bolt-on installation with a 100 A rating and 10 kAIC interrupt capacity, simplifying OEM designs. The combination of compact form, proven protection, and DC shunt-trip capability helps cut downtime while meeting strict electrical codes.
Product Information
Extended Description
BAB3100HS1 Eaton: Quicklag Industrial Thermal-Magnetic Circuit Breaker, Three-pole, 24,48V/dc shunt trip, 100A, 10 kAIC, 240V, Non-Interchangeable
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3100HS1
UPC
786679378649
Product Length/Depth
5 in
Product Height
1 in
Product Width
3 in
Product Weight
0.5 lb
Warranty
1 year
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Thermal magnetic circuit breakers
Amperage Rating
100 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
24,48V/dc shunt trip
Feature: Three-pole, bolt-on installation with 100 A rating and 10 kAIC interrupt capacity. Business Impact: Delivers robust overload and short-circuit protection for three-phase circuits, reducing the risk of cascading faults and unplanned downtime. Application: Ideal for motor feeders and control panels in manufacturing environments. Feature: 24/48 V DC shunt trip option for remote disconnection. Business Impact: Enables rapid safety interlocks and emergency-off workflows, improving workplace safety and risk management. Application: Critical in process control and safety‑critical circuits. Feature: UL Listed and CSA Certified with HACR rating. Business Impact: Streamlines regulatory compliance and panel integration, lowering acceptance testing time. Application: Suitable for NEC-based installations and industry-standard panels. Feature: Compact bolt-on footprint (5 in L × 3 in W × 1 in H). Business Impact: Eases installation in crowded panels and simplifies replacements, reducing labor costs. Application: Common in compact industrial enclosures and upgrade projects. Feature: Non-Interchangeable trip type with 100 A rating. Business Impact: Ensures consistent protection and minimizes risk of misconfiguration in multi-circuit installations. Application: Essential for legacy systems requiring fixed protection characteristics.
