Eaton BAB3100HV Thermal Magnetic Circuit Breaker - UL Listed
Part Number: BAB3100HV
Quick Summary
The Eaton BAB3100HV thermal magnetic circuit breaker protects power circuits in industrial panels, delivering reliable overcurrent protection for demanding equipment. Many engineers face nuisance trips and difficult installations when upgrading protection, so bolt-on mounting and a precise 100 A rating help minimize downtime. It carries UL Listed and CSA Certified marks and is HACR rated for motor protection, supporting safe, compliant installations. With 3-pole, 240 V operation and a 10 kAIC interrupt rating, it simplifies panel design while delivering robust protection and consistent performance. The 50° C calibration and compact form factor support scalable protection across industrial facilities, reducing commissioning time and maintenance costs.
Product Information
Extended Description
BAB3100HV Eaton: Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Bolt-on mounting, Non-automatic,100 A,10 kAIC,Three-pole,240 V,Non-Interchangeable,Q32,BAB
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3100HV
UPC
786679304709
Product Length/Depth
3.8 in
Product Height
4.7 in
Product Width
3.2 in
Product Weight
0.95 lb
Warranty
1 year
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
100 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mounting50° C Calibration
Feature → The BAB3100HV uses Quicklag industrial thermal-magnetic technology with bolt-on mounting, enabling quick, secure installation. Benefit → This reduces commissioning time and downtime while delivering dependable short-circuit protection across demanding industrial power feeds. Application → Ideal for control panels and machine feeders in manufacturing environments where uptime matters and space is at a premium. Feature → 3-pole design rated at 240 V with a 100 A continuous current and 10 kAIC interrupt capacity. Benefit → Provides balanced, high-current protection for three-phase systems, minimizing phase imbalances and equipment stress. Application → Suitable for motor circuits, drive systems, and three-phase feeders in plant automation. Feature → HACR rating plus UL Listed and CSA Certified marks. Benefit → Ensures regulatory compliance, traceability, and motor-protection suitability, reducing validation time for panel builds. Application → Compliance-focused installations in OEM panels and end-user facilities. Feature → Bolt-on mounting and 50° C calibration. Benefit → Simplifies field retrofits and cabinet upgrades, delivering reliable protection in ambient conditions typical of industrial environments. Application → Retrofit projects and new-build panels where fast installation and accurate calibration are critical. Feature → Non-interchangeable trip and 100 A rating. Benefit → Predictable protection behavior, lower risk of mismatched replacements, and streamlined service planning. Application → Standardized protection across a facility’s power distribution network.
