Eaton BAB3100N Thermal Magnetic Circuit Breaker - UL Listed
Part Number: BAB3100N
Quick Summary
The Eaton BAB3100N thermal magnetic circuit breaker provides reliable overload protection for industrial control panels and motor circuits. Engineers face nuisance trips, unclear protection settings, and mounting compatibility challenges; this device addresses these pain points with a robust bolt-on, three-pole design. It carries UL Listed and CSA Certified marks and is HACR rated, ensuring compliance for motor and equipment protection in North American facilities. The 100 A rating, 10 kAIC interrupt capacity, and 240 V operation provide precise protection for demanding environments. With bolt-on mounting and a compact 2.9 in depth, it simplifies installation while delivering dependable protection and long-term cost savings in NEC-compliant infrastructures.
Product Information
Extended Description
BAB3100N Eaton: Eaton Quicklag industrial thermal-magnetic circuit breaker, 100A, BAB type, 10 kAIC, Bolt-on mounting, Three-pole, Non-automatic, Non-Interchangeable, 240V
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BAB3100N
UPC
786679660157
Product Length/Depth
2.9 in
Product Height
2.9 in
Product Width
3 in
Product Weight
1 lb
Warranty
1 year
Certifications
UL Listed CSA Certified
Catalog Notes
HACR rated
Circuit breaker type
BAB
Mounting Method
Bolt-on
Number of poles
Three-pole
Type
Quicklag industrial thermal-magnetic circuit breaker
Amperage Rating
100 A
Interrupt rating
10 kAIC
Trip Type
Non-Interchangeable
Voltage rating
240 V - 240 V
Quantity
32
Special features
Bolt-on mountingNon-automatic
100 A amperage rating paired with a 10 kAIC interrupt level ensures strong protection for 3-phase feeders and motors. This combination minimizes arc flash risk and costly downtime by clearing faults quickly, making it ideal for motor starter panels and distribution blocks in manufacturing lines. The Quicklag thermal-magnetic mechanism blends thermal overload protection with magnetic short-circuit response, delivering selective coordination and faster fault isolation to reduce downstream outages. UL Listed and CSA Certified, with HACR rating, supports NEC compliance for motor-driven equipment in industrial facilities, panels, and cages. Bolt-on mounting and compact dimensions enable straightforward retrofits in existing enclosures, cutting installation time and enabling scalable protection across growing automation lines. Non-automatic, non-interchangeable trip characteristics simplify maintenance and ensure consistent protection without field recalibration. A 1 lb footprint translates to minimal enclosure impact while preserving reliability.
