Eaton BG3023PQ Open Fuse Block - 100 kAIC
Part Number: BG3023PQ
Quick Summary
The Eaton BG3023PQ open fuse block protects three-pole circuits in industrial control panels. Many engineers face challenges with fault isolation and quick fuse replacement in live systems. This unit carries UL Recognized, CSA Certified, and RoHS compliance, with a 100 kAIC short-circuit rating for robust protection. Designed for 600 V systems, it helps minimize downtime while ensuring safe, compliant operation. In addition to its core protection now, it supports seamless integration with Bussmann series components and common panel architectures, delivering reliability and cost efficiency for electrical protection and circuit control applications.
Product Information
Extended Description
BG3023PQ Eaton: Eaton Bussmann series BG open fuse block, 1-20 A, Three-pole, Class G, Pressure plate/quick connect, 100 kAIC, 600 V
Product Name
Eaton Bussmann series BG open fuse block
Catalog Number
BG3023PQ
UPC
051712137195
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.23 lb
Warranty
Not Applicable
Compliances
RoHS Compliant
Certifications
Contact Manufacturer UL Recognized CSA Certified
Amperage Rating
1-20A
Short-circuit rating
100 kA
Voltage rating
600 V
Number of Poles
Three-pole
Class
Class G
Connection
Pressure plate/quick connect
BG3023PQ~BUSS FUSEBLOCK WAS 2094
BG3023PQ~BUSS FUSEBLOCK WAS 2094
Bussmann series Fuseology
Eaton Specification Sheet - BG3023PQ
Three-pole design supports three-phase protection with a compact, open fuse block configuration, enabling straightforward integration into existing control panels. Business impact: faster installation and simplified field maintenance, reducing downtime during fuse changes and routine servicing. Application: industrial automation, machine tooling, and motor control centers. The device handles 1–20 A per pole and 600 V systems, with a 100 kAIC short-circuit rating, delivering reliable fault isolation and safeguarding critical equipment. Business impact: improved safety margins and reduced energy loss through better protection coordination. Application: high-energy applications requiring Class G protection and pressure plate/quick connect terminations. The RoHS compliant construction plus UL Recognized and CSA Certified markings support regulatory compliance, streamlining procurement and audit readiness. Business impact: lower compliance risk and easier supplier qualification for panel builders. Application: OEM and panel shop environments. Compatibility and installation advantages: quick-connect options and standard Bussmann series interfaces improve compatibility with existing fuses and accessories, enabling faster stocking and streamlined maintenance. Business impact: reduced spare-part inventory and faster repair cycles. Application: retrofit projects and new panel builds. Industry context insight: open fuse blocks like BG3023PQ remain a reliable choice for modular, scalable protection in evolving automation architectures, balancing protection levels with cost efficiency.
Get a Quick Quote for a Eaton BG3023PQ
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BG3023PQ?
Enquire Now
FAQs
Install the BG3023PQ using its pressure plate or quick connect terminals, ensuring proper alignment with the panel bus and fuse links. Tighten connections per manufacturer torque recommendations, verify 600 V rating suitability for the circuit, and confirm UL Recognized/CSA Certified markings before energizing. The three-pole configuration supports balanced protection across a three-phase system, enabling safe operation and straightforward maintenance.
The BG3023PQ provides a 1–20 A per-pole amperage range, a 600 V voltage rating, and a 100 kA short-circuit rating. These specifications support robust fault isolation in 600 V motor control environments, minimize arc energy during faults, and enable selective coordination within protection schemes, improving uptime and safeguarding downstream equipment.
Yes. BG3023PQ is part of Eaton’s Bussmann series and uses standard open fuse block interfaces, including pressure plate/quick connect connections. This compatibility simplifies stocking and cross-referencing with existing catalogs, supports easy upgrades in legacy panels, and accelerates installation in OEM and aftermarket projects.
BG3023PQ carries UL Recognized and CSA Certified markings and is RoHS compliant, meeting common regulatory requirements for industrial electrical protection components. These certifications support safe integration into certified assemblies, facilitate supplier qualification, and help pass compliance audits in manufacturing environments.
The BG3023PQ provides fast and safe fuse replacement, reliable fault isolation, and RoHS/UL/CSA compliance, which collectively reduce downtime and maintenance costs. Its three-pole design and compatibility with standard interfaces streamline installation, resulting in lower labor costs and improved overall panel reliability in automation and process industries.
