Eaton BK/ATL-10 Blade Fuse - RoHS
Part Number: BK/ATL-10
Quick Summary
Eaton BK/ATL-10 Blade Fuse is a compact DC protection device designed for control panels and automation circuits. In cramped electrical enclosures, engineers often battle space constraints while needing reliable overcurrent protection. This blade fuse delivers a 32 Vdc rating and a 10 A current capacity with a red color code for quick visual identification, and it is RoHS compliant for sustainability and regulatory alignment. The non-indicating design keeps costs down in high-volume deployments, while the blade-end configuration supports fast, tool-free replacement. For procurement teams, consistent sizing and standard packaging simplify stocking, reduce downtime, and improve maintenance turnaround in industrial environments.
Product Information
Extended Description
BK/ATL-10 Eaton: Eaton Bussmann series ATL blade fuse, Color code red, 32 Vdc, 10A, Non Indicating, Blade fuse, Blade end, Colored plastic housing
Product Name
Eaton Bussmann series ATL blade fuse
Catalog Number
BK/ATL-10
UPC
051712490788
Product Length/Depth
1.4 in
Product Height
1.6 in
Product Width
0.32 in
Product Weight
0.1 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
10 A
Voltage rating
32 Vdc
Material
Colored plastic housing
Packaging type
Standard
Fuse indicator
Non-indicating
Quantity
50
Quantity
50
Special features
Color code red
BK/ATL-10~BK-ATL-10~BULK MICRO III BLADEFUSE
BK/ATL-10~BK-ATL-10~BULK MICRO III BLADEFUSE
Bussmann series Fuseology
Eaton Specification Sheet - BK/ATL-10
Feature → Business Impact → Application: The BK/ATL-10 uses a blade fuse design with a 32 Vdc, 10 A rating, delivering reliable DC protection for industrial control panels and automation hardware; impact is safer equipment operation and minimized risk of tripping in normal operation. This compact 1.4 in length, 1.6 in height, 0.32 in width form factor fits tight panel spaces and reduces busbar crowding, enabling more efficient layouts in motor drives and PLC cabinets. The colored housing, specifically red, accelerates fault diagnosis during maintenance, shortening downtime in production lines and improving overall OEE. The non-indicating fuse minimizes cost and complexity where external indication is not required, while still providing robust protection in low- to mid-current DC circuits. Compatibility with Eaton Bussmann series blade fuses ensures streamlined replacements and inventory control, reducing spare part variety and procurement effort.
Get a Quick Quote for a Eaton BK/ATL-10
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BK/ATL-10?
Enquire Now
FAQs
BK/ATL-10 uses a standard blade-end design compatible with most Eaton Bussmann blade fuse holders and common automotive/industrial fuse blocks. Its 1.4 in length and 0.32 in width optimize space in compact control panels, while maintaining reliable contact and straightforward replacement during routine maintenance.
Select BK/ATL-10 for up to 32 Vdc and 10 A to protect DC circuits in automation equipment. This rating aligns with typical low- to mid-current control circuits in PLCs and instrumentation panels, offering predictable protection without nuisance trips in normal operating surges.
Yes, the BK/ATL-10 is RoHS compliant, meaning it complies with restrictions on hazardous substances. For projects targeting green compliance and reduced regulatory risk, this fuse supports environmentally responsible design without sacrificing electrical protection.
The fuse measures 1.4 in in length, 1.6 in in height, and 0.32 in in width, with a colored housing for quick identification. These compact dimensions enable installation in crowded control cabinets and near densely packed power distribution components, reducing confinement issues and simplifying routing.
Ideal for DC protection in control panels, automation cabinets, and motor drive interfaces where space is at a premium. Its standard packaging (50 per box) and non-indicating design lower per-unit cost, while reliable protection reduces downtime and maintenance costs, delivering measurable return on investment in high-volume deployments.
