Eaton BK/ATL-5 Blade Fuse - 32 Vdc, 5 A, RoHS Compliant
Part Number: BK/ATL-5
Quick Summary
The Eaton BK/ATL-5 blade fuse provides fast DC overcurrent protection for control panels and power distribution. Engineers often wrestle with compatibility, color coding, and RoHS compliance when trying to fit fuses into compact panel layouts. This RoHS compliant fuse is designed to integrate with the Eaton Bussmann line to simplify sourcing and spares compatibility. By using BK/ATL-5, maintenance teams gain consistent DC protection, easy replacement, and streamlined procurement across multiple control panels. With a compact footprint and color-coded red housing, it minimizes space usage while helping technicians identify the correct fuse quickly. Each 50-piece quantity supports stocking for widespread panel deployments, reducing downtime during repairs.
Product Information
Extended Description
BK/ATL-5 Eaton: Eaton Bussmann series ATL blade fuse, Color code red, 32 Vdc, 5A, Non Indicating, Blade fuse, Blade end, Colored plastic housing
Product Name
Eaton Bussmann series ATL blade fuse
Catalog Number
BK/ATL-5
UPC
051712490764
Product Length/Depth
1.4 in
Product Height
1.6 in
Product Width
0.32 in
Product Weight
0.1 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
5 A
Voltage rating
32 Vdc
Material
Colored plastic housing
Packaging type
Standard
Fuse indicator
Non-indicating
Quantity
50
Quantity
50
Special features
Color code red
BK/ATL-5~BK-ATL-5~BULK MICRO II BLADE FUSE
BK/ATL-5~BK-ATL-5~BULK MICRO II BLADE FUSE
Bussmann series Fuseology
Eaton Specification Sheet - BK/ATL-5
Feature: The BK/ATL-5 provides a robust 32 Vdc, 5 A electrical rating, delivering precise DC overcurrent protection for durable industrial circuits. This rating helps prevent nuisance trips in normal operation while safeguarding critical components like controllers, sensors, power supplies, and communications lines. Application: Best suited for control panels and DC power distribution networks where space is limited and reliable protection is essential. Feature: Blade-end design with a standard blade fuse format enables straightforward installation into widely used fuse holders. Business impact: Quick, tool-free replacements reduce downtime, improve maintenance predictability, and lower service costs in fast-rotation environments. Application: Compatible with Eaton Bussmann series holders and compatible panel assemblies, making retrofits and new builds simpler for engineers. Feature: Color-coded red housing paired with a colored plastic body supports immediate visual identification. Business impact: This reduces human error during assembly and service, speeding part verification and stocking accuracy in high-mix systems. Application: Particularly valuable in multi-panel environments, where technicians must rapidly distinguish correct fuses during routine maintenance. Feature: Non-indicating fuse indicator simplifies inventory and reduces cost by eliminating indicator components. Business impact: Lower part count minimizes failure points and streamlines procurement, especially for high-volume OEM deployments. Application: Suited for applications where visual status indicators are unnecessary but fast, reliable DC protection is required. Feature: RoHS compliant construction with standard 50-piece packaging supports sustainable manufacturing and efficient stocking. Business impact: Ensures regulatory alignment across facilities and reduces procurement cycle times by enabling bulk ordering. Application: Ideal for manufacturing floors, system integrators, and OEMs needing consistent sourcing for DC protection fuses.
Get a Quick Quote for a Eaton BK/ATL-5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BK/ATL-5?
Enquire Now
FAQs
BK/ATL-5 uses a standard blade-end format, designed to fit common fuse holders found in industrial control panels. The 1.4 inch length, 0.32 inch width, and 1.6 inch height enable straightforward mounting in tight spaces. Use within Eaton Bussmann compatible assemblies and ensure the 32 Vdc, 5 A rating matches the protected circuit to avoid nuisance trips or inadequate protection.
The fuse is rated for 32 Vdc and 5 A, providing DC overcurrent protection for low-voltage power distribution in industrial environments. This non-indicating design focuses on reliable protection without indicator hardware, reducing potential failure points. Ensure the circuit operates within these limits and select a higher rating only if the load current regularly approaches the fuse rating to prevent nuisance blowing.
Yes. The BK/ATL-5 is purpose-built for DC protection in control panels and DC power distribution networks. Its compact blade fuse form factor, red color code for quick identification, and RoHS compliance support robust, maintenance-friendly installations across diverse industrial applications while keeping spare parts management efficient.
The BK/ATL-5 is RoHS compliant, aligning with environmental and regulatory requirements in many manufacturing contexts. For additional certifications beyond RoHS, consult the factory or Eaton documentation to confirm UL/CE or other certifications relevant to your region and industry before procurement.
With a 50-piece packaging quantity, BK/ATL-5 supports bulk stocking for multiple panels, reducing downtime during replacements and streamlining replenishment cycles. The color-coded red housing aids rapid identification, lowering maintenance time and human error. Overall, it delivers predictable spare availability, improved service levels, and lower lifecycle costs for DC protection in busy facilities.
