Eaton BK/SC-1-1/2 Fuse - Class G, 100 kAIC at 600 Vac
Part Number: BK/SC-1-1/2
Quick Summary
The Eaton Bussmann BK/SC-1-1/2 fuse is a current-limiting fast-acting device used for branch circuit protection. Engineers often struggle to balance small form factors with the high interrupt ratings needed for HVAC and control-panel circuits. RoHS compliant and built to Class G specifications with a rejection-style, non-indicating design, it supports quick field checks and safer maintenance. Bulk packaging and compact dimensions (1.31 in L) help reduce inventory footprint while enabling reliable HVAC branch circuit protection. With a 1.5 A rating and interrupt ratings of 100 kAIC at 600 Vac and 10 kAIC at 170 Vdc, it delivers robust protection under short-circuit events while supporting easy installation in standard bulk packaging.
Product Information
Extended Description
BK/SC-1-1/2 Eaton: Eaton Bussmann series SC fuse, Current-limiting fast acting fuse, Rejection style, Fusible branch panelboards, HVAC branch circuit protection, 1.5 A, Class G, Non-indicating, 10 kAIC at 170 Vdc, 100 kAIC at 600 Vac, Bulk, 600 V, 170 Vdc
Product Name
Eaton Bussmann series SC fuse
Catalog Number
BK/SC-1-1/2
UPC
051712135665
Product Length/Depth
1.31 in
Product Height
0.41 in
Product Width
0.41 in
Product Weight
0.1 lb
Warranty
Not Applicable
Compliances
Not Applicable RoHS Compliant
Catalog Notes
Bulk
Amperage Rating
1.5 A
Interrupt rating
100 kAIC at 600 Vac 10 kAIC at 170 Vdc
Voltage rating
600 Vac, 170 Vdc
Packaging type
Standard Bulk
Class
Class G
Fuse indicator
Non-indicating
Special features
Rejection style
BK/SC-1-1/2~BK-SC-1-1-2~BUSS SC FUSE CLASS G
BK/SC-1-1/2~BK-SC-1-1-2~BUSS SC FUSE CLASS G
Bussmann series Fuseology
Eaton Specification Sheet - BK/SC-1-1/2
Feature: Current-limiting fast-acting SC fuse. Business impact: Rapid fault isolation reduces arcing energy, minimizes downtime, and extends equipment life in critical HVAC and control-panel applications. Application: Ideal for fusible branch panelboards and HVAC branch circuit protection where high interrupt capability is required without oversized components. Long-tail keywords: Eaton Bussmann series SC fuse, current-limiting fast-acting fuse, rejection style fuse, Class G fuse, HVAC protection. Feature: Compact form factor (1.31 in L, 0.41 in W, 0.41 in H) and bulk packaging. Business impact: Saves panel space and lowers procurement costs, enabling easier stocking and faster replacement in industrial environments. Application: Control panels with limited enclosure area and bulk-bulk purchasing workflows. Long-tail keywords: compact fuse dimensions, bulk packaging, standard bulk packaging. Feature: High interrupt ratings (100 kAIC at 600 Vac, 10 kAIC at 170 Vdc). Business impact: Safer outage handling and reduced collateral damage in power-distribution networks. Application: Industrial HVAC and equipment protection where rigorous short-circuit performance is required. Long-tail keywords: 100 kAIC at 600 Vac, 10 kAIC at 170 Vdc, high interrupt capability. Feature: Rejection style and non-indicating design. Business impact: Reduces misinstallation risk and simplifies maintenance checks, improving uptime. Application: Panelboard installations and replacement workflows. Long-tail keywords: rejection style fuse, non-indicating fuse, easy maintenance. Feature: RoHS compliant and Class G fuse designation. Business impact: Meets regulatory expectations while aligning with standard electrical protection practices. Application: Regulatory-compliant HVAC and control-panel protection across manufacturing environments. Long-tail keywords: RoHS compliant fuse, Class G protection, standard fuse classification.
Get a Quick Quote for a Eaton BK/SC-1-1/2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BK/SC-1-1/2?
Enquire Now
FAQs
Install BK/SC-1-1/2 in standard bulk panel assemblies with compatible Bussmann SC fuse holders. The device features a compact 1.31 inch length and a rejection-style design to prevent incorrect insertion. Confirm voltage ratings of 600 Vac and 170 Vdc and ensure the panel equipment supports Class G fuses. Maintain proper clearance and follow OEM wiring diagrams to maximize protection and minimize nuisance trips.
The fuse is rated for 1.5 A with interrupt ratings of 100 kAIC at 600 Vac and 10 kAIC at 170 Vdc. Voltage ratings are 600 Vac and 170 Vdc. These specs support fast fault isolation in HVAC and control circuits while maintaining safe operation in high-energy environments. Design plans should account for worst-case fault currents and select this fuse when the system requires high interrupt capability in a compact form.
Yes. The BK/SC-1-1/2 is designed for HVAC branch circuit protection, offering a current-limiting, fast-acting profile that reduces damage during faults. Its bulk packaging helps with procurement for large installations, and the Class G designation aligns with common electrical protection standards in HVAC cabinets. It supports reliable operation under typical HVAC load profiles.
The fuse is RoHS compliant, aligning with lead-free and restricted substance requirements. It carries the standard Class G fuse designation and non-indicating, rejection-style features that simplify maintenance and replacement workflows. There are no further certifications listed beyond RoHS compliance in the provided data, so verify with your internal compliance team for any jurisdiction-specific approvals.
The BK/SC-1-1/2 reduces downtime through fast fault isolation (high interrupt ratings) and lowers stocking complexity with bulk packaging. Its compact size saves panel space, and RoHS compliance supports regulatory adherence. Overall, you gain improved reliability, easier maintenance, and potentially lower spare-part inventory costs in HVAC and control-panel ecosystems.
