Eaton BKG2M100B Pow-R-Xpress Main Breaker Kit - UL 67
Part Number: BKG2M100B
Quick Summary
The Eaton BKG2M100B Pow-R-Xpress main breaker kit is a compact protection module designed to provide reliable 100A main protection for panelboards in industrial environments. Engineers often face retrofit downtime and complex wiring during protection upgrades, which can delay critical projects. UL 67 listed and NEMA compliant, this kit supports safe, code-conforming installations across regions. This solution speeds stocking and upgrades, delivering dependable panelboard protection and reducing field downtime.
Product Information
Extended Description
BKG2M100B Eaton: Eaton Pow-R-Xpress Main Circuit Breaker Kit, PDG2XM, BOT MNT, 100A
Product Name
Eaton Pow-R-Xpress main breaker kit
Catalog Number
BKG2M100B
UPC
786689365547
Product Length/Depth
6 in
Product Height
3 in
Product Width
4 in
Product Weight
5 lb
Compliances
NEMA Compliant
Certifications
UL 67
Type
BOT MCB KIT
Amperage Rating
100A
Rated operational current
100A
Pow-R-Xpress stocking program flyer
Pow-R-Xpress stocking program flyer
Pow-R-Xpress stocking program flyer
Pow-R-Line Xpert family overview
Eaton Specification Sheet - BKG2M100B
The BKG2M100B Pow-R-Xpress main breaker kit delivers a true 100A protection appliance that directly reduces the risk of overloads in distributed power systems, with clear business impact in uptime and safety. Bot-mount (BOT MNT) mounting simplifies integration into existing panelboards, accelerating installation and reducing project labor costs for retrofit or new builds. Its compact 6 x 4 x 3 inch footprint and 5 lb weight improve handling in tight electrical spaces, lowering installation fatigue and potential damage during fitment. With UL 67 certification and NEMA compliance, the kit aligns with stringent safety standards, minimizing regulatory review time and accelerating approval cycles for facilities upgrades. The Pow-R-Xpress stocking program compatibility enhances procurement efficiency, ensuring rapid availability and reducing downtime in maintenance windows. This combination supports scalable protection for critical loads while enabling straightforward wiring practices and future expandability for a growing electrical infrastructure.
Get a Quick Quote for a Eaton BKG2M100B
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BKG2M100B?
Enquire Now
FAQs
Installation begins by confirming panelboard compatibility with BOT MNT breakers and verifying a 100A protection requirement. Mount the kit to the bottom mounting points, connect the main feed and load conductors per the panel’s wiring diagram, secure all terminations, and perform insulation and clearance checks. Follow safety procedures and consult Eaton installation guides for any product-specific torque values and sequence recommendations to ensure reliable operation.
The BKG2M100B provides a 100A amperage rating and a rated operational current of 100A, suitable for panelboard protection of mid-to-large loads. It carries UL 67 certification and is NEMA compliant, supporting safe use in regulated environments. Dimensions are 6 in length, 4 in width, and 3 in height, with an approximate weight of 5 lb, aiding fitment in constrained spaces.
Yes, the BKG2M100B is designed for panelboard protection upgrades, especially where a 100A main breaker is required. Its BOT MNT design and compact footprint facilitate retrofits in existing installations without major enclosures changes. The UL 67 and NEMA compliance support code-conformant upgrades, while compatibility with Pow-R-Xpress stock management helps shorten procurement lead times.
Key verifications include UL 67 certification, which confirms electrical safety for panelboard protection devices, and NEMA compliance, indicating suitability for common electrical environments. Ensure mounting compatibility (BOT MNT) and confirm the 100A rating aligns with your panel’s bus rating and feeder protection requirements to meet local electrical codes.
The kit reduces downtime by enabling faster stock-to-install cycles through Eaton's Pow-R-Xpress program, lowering field labor costs and minimizing panel interruption during upgrades. Its standardized 100A protection, compact form factor, and simple wiring approach also reduce commissioning time and help maintain system reliability across maintenance windows.
