Eaton BP/ATR-10ID Blade Fuse - easyID LED, 32 Vdc, 10 A
Part Number: BP/ATR-10ID
Quick Summary
BP/ATR-10ID blade fuse provides fast overcurrent protection for DC control circuits in automation panels. When incorrect fusing leads to nuisance trips and unplanned downtime, maintenance becomes costly. This device carries RoHS compliance, a 1 kA interrupt rating, and 32 Vdc operation to support safe, reliable DC protection. For business value, this blade fuse offers easyID identification and a durable zinc element that reduces maintenance time. In practice, engineers rely on the red color code and LED indicator to speed fault isolation and improve panel uptime. This aligns with reliability-driven procurement, delivering predictable performance in automotive and industrial settings. The device’s compact size and retail packaging facilitate stocking and on-site replacements across diverse installations.
Product Information
Extended Description
BP/ATR-10ID Eaton: Eaton Bussmann series ATR easyID blade fuse, Color code red, 32 Vdc, 10A, 1 kAIC, LED, easyID blade fuse, Blade end, Colored plastic housing, zinc fuse element
Product Name
Eaton Bussmann series ATR easyID blade fuse
Catalog Number
BP/ATR-10ID
UPC
051712742283
Product Length/Depth
0.35 in
Product Height
0.6 in
Product Width
0.14 in
Product Weight
0.14 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
10 A
Interrupt rating
1 kAIC
Voltage rating
32 Vdc
Material
Zinc fuse element Colored plastic housing
Packaging type
Retail
Fuse indicator
LED
Special features
Color code red
LED indicator and color-coded housing deliver immediate status visibility, enabling quick fault verification and reducing mean time to repair in high-density panels. The result is lower maintenance costs and faster recovery after faults, especially on DC power rails that feed programmable controllers and sensors. Rugged construction uses a zinc fuse element with colored plastic housing that supports reliable operation in harsh industrial environments while blade-end compatibility ensures easy installation in existing Bussmann ATR holders. Electrical ratings—32 Vdc, 10 A, and 1 kAIC—provide appropriate protection without nuisance trips for typical automation circuits, helping minimize collateral damage during fault events and supporting safe disconnection of faulty circuits. Compliance and traceability are aided by RoHS adherence and clear identification through easyID; the retail packaging simplifies stocking and on-site replacements. Some panels may require higher interrupt ratings or CE certifications; BP/ATR-10ID offers a compact, cost-effective DC protection solution with straightforward integration and maintenance workflows, reducing engineering time and inventory complexity in modernization projects. In the field, technicians appreciate fast fault isolation, reduced downtime, and consistent protection across devices within the ATR family, enabling more predictable performance in manufacturing and process environments.
Get a Quick Quote for a Eaton BP/ATR-10ID
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BP/ATR-10ID?
Enquire Now
FAQs
Install the BP/ATR-10ID in a compatible blade-end fuse holder designed for DC circuits. Ensure power is off before handling, then insert the blade ends fully seated and secure. The 32 Vdc rating and 10 A current rating protect the circuit without nuisance trips, while the color coded housing helps you identify the device quickly in dense panels.
BP/ATR-10ID provides a 32 Vdc voltage rating, a 10 A amperage rating, and a 1 kAIC interrupt rating. These specs define the maximum operating voltage, load current, and fault-clearing capability, respectively. Together they tailor protection for low‑voltage DC control circuits and ensure rapid isolation of faults while minimizing collateral damage to nearby components.
Yes. BP/ATR-10ID is part of the Bussmann ATR easyID blade fuse family and uses a blade-end format common to ATR devices. This promotes straightforward replacement in standard blade fuse holders and aligns with color code red identification. For panel builders, compatibility reduces redesign time and helps maintain consistent fuse strategies across machines.
RoHS compliance is documented, with the data advising to contact the factory for any additional certifications. The BP/ATR-10ID is designed for DC protection in control panels; however, CE, SIL, and IP ratings are not listed in the provided data. Always verify regulatory requirements with Eaton or your compliance team to ensure alignment with local standards and project specs.
The BP/ATR-10ID fuse includes an LED indicator to signal status at a glance, reducing troubleshooting time in live consoles. This visibility supports proactive maintenance, quick fault isolation, and less guesswork during inspection. In high-density panels, the LED status combined with color coding (red) helps operators verify protection without removing components.
