Eaton BP/ATR-30ID Blade Fuse - 1 kAIC, 35 Vdc RoHS
Part Number: BP/ATR-30ID
Quick Summary
BP/ATR-30ID is an ATR easyID blade fuse that protects DC circuits in compact industrial controls. This design helps technicians avoid incorrect replacements and reduces maintenance downtime. RoHS compliance ensures lead-free materials; in addition, an integrated LED status indicator enables rapid fault identification. For business value, this compact DC protection solution streamlines spares management and supports reliable panel protection in automation environments.
Product Information
Extended Description
BP/ATR-30ID Eaton: Eaton Bussmann series ATR easyID blade fuse, Color code green, 35 Vdc, 30A, 1 kAIC, LED, easyID blade fuse, Blade end, Colored plastic housing, zinc fuse element
Product Name
Eaton Bussmann series ATR easyID blade fuse
Catalog Number
BP/ATR-30ID
UPC
051712742313
Product Length/Depth
0.35 in
Product Height
0.6 in
Product Width
0.14 in
Product Weight
0.14 lb
Compliances
RoHS Compliant Contact factory
Amperage Rating
30 A
Interrupt rating
1 kAIC
Voltage rating
35 Vdc
Material
Zinc fuse element Colored plastic housing
Packaging type
Retail
Fuse indicator
LED
Special features
Color code green
Feature: LED indicator and color coding (green) provide immediate fault visibility. Business Impact: Reduces field diagnostic time and minimizes guesswork during maintenance. Application: Ideal for DC protection in compact automation panels where quick status is critical. Feature: 30 A amperage rating with 1 kAIC interrupt rating at 35 Vdc. Business Impact: Delivers reliable overcurrent protection for DC circuits in motor drives and battery systems, lowering risk of equipment damage. Application: Suitable for industrial control panels, battery management, and DC power rails. Feature: Zinc fuse element with colored plastic housing and blade end. Business Impact: Enhances durability and ease of replacement in tight spaces, reducing service time. Application: Retail-packaged blade fuses in panel boards or assembly lines. Feature: EasyID labeling and compatibility with standard blade holders. Business Impact: Streamlines asset tagging and quick replacements, cutting downtime in maintenance windows. Application: OEM panel builds and retrofit projects. Feature: RoHS compliant construction. Business Impact: Facilitates global regulatory compliance and reduces compliance costs across multinational deployments. Application: Global manufacturing environments where lead-free materials are required.
Get a Quick Quote for a Eaton BP/ATR-30ID
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BP/ATR-30ID?
Enquire Now
FAQs
Yes. The BP/ATR-30ID uses a blade-end configuration designed for easy drop-in replacement in standard blade fuse holders commonly found in compact DC panels. Its 0.35 in depth and 0.14 in width fit within tight panel envelopes, while the 30 A rating ensures suitable protection for 35 Vdc DC power rails typical in automation equipment.
The fuse is rated for 30 A with an interrupt capacity of 1 kA at 35 Vdc. This means it will interrupt a fault current up to 1 kA without sustaining damage, protecting DC circuits in applications such as motor drives and battery systems from overcurrent events while minimizing nuisance tripping during normal operation.
Ideal for industrial automation panels, compact control cabinets, battery management systems, and motor drive enclosures. Its compact form factor, LED status, and easyID labeling make it well-suited for OEM equipment, retrofits, and serviceable panels in manufacturing, energy storage, and process automation sectors.
The product is RoHS compliant, aligning with lead-free material requirements for many global markets. Additional certifications may be available by contacting Eaton for specifics; RoHS compliance ensures readiness for use in most modern electronics manufacturing, while other regulatory markings should be verified per regional requirements during procurement.
With an LED indicator and color coding, field diagnostics become faster, reducing downtime during fault tracing. The reliable 30 A/35 Vdc protection minimizes unplanned outages, while easyID labeling simplifies spare parts management and maintenance scheduling, delivering measurable improvements in panel uptime and total cost of ownership.
