Eaton BP/NON-15 NON fuse - 50 kAIC
Part Number: BP/NON-15
Quick Summary
Eaton BP/NON-15 NON fuse provides reliable overload protection for small control circuits in industrial equipment. Engineers often struggle to choose fuses that balance protection with cost and space constraints in compact panels. This part delivers a non-current-limiting solution with a 15 A rating, Class K5 construction, and a robust 50 kAIC interrupt rating at 250 Vac and 125 Vdc, backed by CE marking for international compliance. Its non-indicating design keeps panel visuals clean, while the ferrule-end terminations simplify installation in standard wiring harnesses. By combining compact form with proven Eaton Bussmann performance, it supports faster procurement, reduced stock-keeping, and longer service intervals in automation and machine-building environments.
Product Information
Extended Description
BP/NON-15 Eaton: Eaton Bussmann series NON fuse, Non current limiting, Light duty circuit locations, 15 A, Class K5, Non-indicating, Ferrule end x ferrule end, 50 kAIC at 250 Vac, 50 kAIC at 125 Vdc, Blister pack, 250 V, 125 Vdc
Product Name
Eaton Bussmann series NON fuse
Catalog Number
BP/NON-15
UPC
051712111010
Product Length/Depth
2 in
Product Height
0.81 in
Product Width
0.81 in
Product Weight
0.1 lb
Compliances
CE Marked
Amperage Rating
15 A
Interrupt rating
50 kAIC at 250 Vac 50 kAIC at 125 Vdc
Voltage rating
250 Vac, 125 Vdc
Packaging type
Standard Blister
Class
Class K5
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Special features
Rejection style
BP/NON-15~BP-NON-15~BUSS ONE TIME FUSE
BP/NON-15~BP-NON-15~BUSS ONE TIME FUSE
Bussmann series Fuseology
Eaton Specification Sheet - BP/NON-15
Non-current-limiting design paired with a 15 A rating reduces nuisance trips and stabilizes small loads in control panels, lowering maintenance costs for automation equipment. In practice, this means predictable protection without aggressive current limiting, suitable for light-duty circuits such as relay panels and sensor subsystems, where space is at a premium. The non-indicating, Class K5 construction minimizes panel clutter and eliminates visual indicators that complicate commissioning, improving readability and reducing error-prone wiring during startup. Ferrule-end terminations provide secure, consistent connections with standard wiring harnesses, speeding installation and simplifying replacements in field service. With a 50 kAIC interrupt rating at 250 Vac and 125 Vdc, this fuse delivers safe disconnection during fault events, enhancing overall machine safety. CE marking confirms EU regulatory compliance, enabling cross-border projects. The compact footprint—2 in long and about 0.81 in square—supports dense panel layouts in control cabinets, HMI enclosures, and small automation panels. Standard blister packaging facilitates stocking and quick deployment at the point of use.
Get a Quick Quote for a Eaton BP/NON-15
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BP/NON-15?
Enquire Now
FAQs
BP/NON-15 is a non-current-limiting fuse from Eaton’s Bussmann series designed for light-duty circuit protection in industrial equipment. It provides 15 A protection with a Class K5 rating and a 50 kAIC interrupt capacity at 250 Vac and 125 Vdc. Use it in control panels, small automation devices, and instrument power rails where compact, reliable protection is required and where current limiting is not necessary.
Install BP/NON-15 by inserting the ferrule-ended leads directly into compatible ferrule-ready terminals inside the panel. Ensure the contact surfaces are clean, seats are snug, and the fuse is oriented per the panel’s wiring diagram. The ferrule ends provide secure, vibration-resistant connections, enabling quick field replacements without special adapters and supporting reliable long-term operation in harsh environments.
BP/NON-15 is part of Eaton’s Bussmann series and uses standard ferrule-terminals common to Bussmann fuses. While it is optimized for BP/NON-15 applications, it maintains compatibility with Bussmann ferrule assemblies and similar IEC/UL-style panel wiring schemes, ensuring straightforward substitutions within light-duty protection schemes without compromising electrical clearance, termination, or panel layout.
BP/NON-15 is CE marked, rated for 15 A with an interrupt rating of 50 kAIC at 250 Vac and 125 Vdc, and supports 250 Vac / 125 Vdc operation. It features Class K5 construction and non-indicating operation. These specifications make it suitable for EU-compliant installations and a wide range of North American applications requiring reliable, predictable protection in light-duty circuits.
The non-indicating, compact BP/NON-15 fuse reduces visual clutter and simplifies commissioning, which can shorten startup time and reduce commissioning errors. Its high interrupt rating supports safer fault handling, potentially lowering downtime costs. With a reliable 15 A rating for small loads, it helps minimize unexpected fuse trips in essential control circuits, contributing to lower maintenance intervals and improved overall equipment availability.
