Eaton BQL3100 Circuit Breaker - 10 kAIC
Part Number: BQL3100
Quick Summary
The Eaton BQL3100 circuit breaker protects electrical panels by interrupting faults in commercial and industrial power circuits. These facilities often struggle with nuisance tripping and challenging bolt-on replacements in crowded switchgear. HACR rated compliance helps ensure safer operation across HVAC and motor-driven loads. Designed for three-pole service at 100 A with Cu/Al conductors, it integrates seamlessly into Eaton bolt-on frames. In practice, this combination delivers reliable protection, quick replacement, and predictable maintenance costs. The compact 5 in x 3 in x 3 in envelope and bolt-on mounting support fast, reliable installation in retrofit projects.
Product Information
Extended Description
BQL3100 Eaton: BQL Classic Replacement Circuit Breakers, Bolt-on, 100A, #8-2/0 AWG, Cu/Al, Three-pole, 10 kAIC at 120/240V
Product Name
Eaton BAB thermal magnetic circuit breaker
Catalog Number
BQL3100
UPC
782114304198
Product Length/Depth
5 in
Product Height
3 in
Product Width
3 in
Product Weight
0.5 lb
Compliances
HACR Rated
Circuit breaker type
BQL
Number of poles
Three-pole
Type
Classic replacement circuit breaker
Wire size
#8-2/0 AWG Cu/Al
Amperage Rating
100 A
Interrupt rating
10 kAIC at 120/240 Vac
Voltage rating
120/240 V
Feature: Bolt-on classic replacement design simplifies retrofits in legacy Eaton frames. Business impact: Reduces retrofit labor and downtime, accelerating panel upgrades. Application: Retrofit aging control panels and crowded enclosures without extensive rewiring, minimizing project timelines and field risk. Feature: Three-pole construction provides synchronized interruption across all phases. Business impact: Improves protection for 3-phase systems and reduces unbalanced faults. Application: Suitable for industrial control panels and distribution boards requiring coordinated tripping. Feature: 100 A amperage rating with Cu/Al conductors up to #8-2/0 AWG. Business impact: Maximizes wiring flexibility and feeder capability without panel redesign. Application: Power feeds in machine controls, conveyors, and other industrial equipment. Feature: 10 kAIC interrupt rating at 120/240 Vac. Business impact: High fault-current tolerance protects equipment and reduces downstream damage. Application: Service entrances and distribution networks in demanding industrial environments. Feature: HACR rated compliance supports HVAC and motor loads. Business impact: Fewer nuisance trips and safer operation for thermal management circuits. Application: HVAC control panels, motor control centers, and lighting panels in factories. Feature: Compact 5 x 3 x 3 in footprint and 0.5 lb weight. Business impact: Space savings and easier handling in retrofit projects. Application: Crowded enclosures and new builds where dimensions constrain component choice.
Get a Quick Quote for a Eaton BQL3100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BQL3100?
Enquire Now
FAQs
The BQL3100 is designed as a bolt-on classic replacement circuit breaker for Eaton BQL panels, three-pole, Cu/Al wiring up to #8-2/0 AWG, with a 100 A rating and 10 kAIC at 120/240 V. It matches standard Eaton bolt-on frames and 5x3x3 in footprint, enabling straightforward swaps without large enclosure modifications.
Amperage rating: 100 A. Interrupt rating: 10 kAIC at 120/240 Vac. Voltage rating: 120/240 V. Wire size: Cu/Al up to #8-2/0 AWG. Poles: Three-pole. Compliance: HACR rated. This combination supports reliable protection for three-phase systems in industrial environments.
Ideal for industrial control panels, three-phase distribution boards, and retrofit projects where reliable, space-efficient protection is needed. Its classic bolt-on design, 100 A rating, and 10 kAIC interrupt capability make it suitable for motor loads, conveyors, and other heavy-duty equipment in crowded enclosures.
HACR rated means the breaker is suitable for heating, air conditioning, and refrigeration circuits. It helps reduce nuisance trips on HVAC-related loads and provides safer, more dependable operation in motor-driven environments, aligning with typical industry practices for HVAC and related equipment protection.
Using the BQL3100 enables faster replacements with minimal panel modification, reducing downtime and labor costs. Its compatibility with existing Eaton bolt-on frames and standard Cu/Al wiring simplifies procurement and stocking, contributing to predictable maintenance budgets and longer service intervals for aging control and distribution panels.
