Eaton BRH125 BR thermal magnetic circuit breaker - 22 kAIC
Part Number: BRH125
Quick Summary
The Eaton BRH125 BR thermal magnetic circuit breaker provides reliable overcurrent protection for 1-pole circuits in 120/240V panels used in industrial and commercial environments. This helps avoid nuisance trips and compatibility issues with BR load centers, minimizing installation delays and service interruptions while improving uptime for critical automation circuits. Certified to UL 490 and Federal Specifications W-C376, with options for HACR and shunt-trip for broader building code compliance. Designed for Type BR load centers, it facilitates fast upgrades and consistent safety across main and sub-panels. Its compact 1-Inch plug-on design simplifies installation in existing BR Loadcenters, while listing and catalog notes support rapid ordering and field replacement.
Product Information
Extended Description
BRH125 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,25 A,22 kAIC,Single-pole,120/240V,BRH,#14-4 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRH125
UPC
786676373159
Product Length/Depth
3 in
Product Height
2.9 in
Product Width
1 in
Product Weight
0.3 lb
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Voltage rating
120/240 V
Circuit breaker type
BR
Interrupt rating
22 kAIC
Main circuit breaker
BRH
Wire size
#14-4 AWG Cu/Al
Number of poles
Single-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - BRH125
Eaton type BR circuit breaker limited warranty June 2024
Paragraph 1: Feature: The 1-Inch plug-on design of the BRH125 keeps wiring straightforward and minimizes panel downtime by allowing quick replacement without removing the bus. Business Impact: this reduces labor time, lowers field error risk, and stabilizes maintenance schedules, improving overall equipment availability. Application: ideal for Type BR Loadcenters and 120/240 V distributions in light commercial and industrial panels.Paragraph 2: Feature: 25 A rating with a 22 kAIC interrupt capacity delivers robust fault clearance for motor starters and lighting circuits. Business Impact: higher fault tolerance translates to fewer nuisance trips under surge conditions and greater protection for connected equipment. Application: well-suited for BR Loadcenters in HVAC controls, manufacturing lines, and critical power feeds.Paragraph 3: Feature: UL 490 certification and Federal Specifications W-C376 compliance align with common regulatory requirements. Business Impact: supports faster procurement, easier audit trails, and proven performance in standardized environments. Application: commonly used in both new builds and retrofit projects across residential, commercial, and light industrial installations.Paragraph 4: Feature: Copper/Aluminum wire compatibility up to #14-4 AWG enables flexible terminations with widely used conductors. Business Impact: reduces rewiring needs, simplifies stocking, and accelerates field termination processes. Application: plug-on BRH125 installations across panelboards where Cu or Al conductors are used.Paragraph 5: Feature: Catalog notes indicate availability in switching duty, HACR, shunt-trip, and high magnetic variants. Business Impact: allows engineers to tailor protection to load profiles, improving safety margins and code compliance. Application: enables custom configurations for motors, HVAC, and other high-demand loads in BR Loadcenters.Paragraph 6: Feature: Industry-ready documentation and cross-reference data accompany BRH125, including wiring diagrams, catalog notes, and datasheets. Business Impact: reduces procurement lead times and minimizes mis-orders across teams. Application: supports field engineering, maintenance planning, and training programs.Paragraph 7: Feature: Global availability and consistent datasheet language aid international projects. Business Impact: simplifies multi-site deployments, minimizes translation errors, and aligns with global electrical standards. Application: ideal for multinational facilities and OEM integrations.
