Eaton BRH135 Thermal Magnetic Breaker - 22 kAIC

Feature: Type BR 1-Inch plug-on circuit breaker enables quick installation and tidy panel layouts. Benefit: Reduces installation time and panel depth while ensuring compatibility with BR Loadcenters, improving project timelines in electrical distribution. Application: Ideal for residential and light-commercial panels where space is at a premium. Feature: 35 A amperage rating at 120/240 V. Benefit: Provides targeted protection for branch circuits and feeders, minimizing nuisance trips and extending equipment life. Application: Common for lighting, controls, and small motor circuits in BR load centers. Feature: Interrupt rating of 22 kAIC. Benefit: High fault-clearing capability improves safety margins and compliance with NEC/IEEE standards for fault currents. Application: Suitable for systems with moderate to high available fault current. Feature: Single-pole design with main BRH compatibility. Benefit: Streamlined integration into Type BR Loadcenters and simplified spare parts planning. Application: Efficiently protects individual branch circuits within modular distribution panels. Feature: Wire size compatibility #14-4 AWG Cu/Al. Benefit: Flexible wiring options support common field layouts and reduce rework. Application: Branch circuit connections in both copper and aluminum installations. Feature: Certifications and compliance including UL 490 and Federal Specifications W-C376. Benefit: Regulatory alignment reduces risk during audits and guarantees baseline safety standards. Application: Essential for code-compliant installations in industrial and commercial settings. Feature: Catalog notes indicate switching duty, HACR, shunt trip and high magnetic setting options. Benefit: Offers configurability to meet specific protection schemes and control strategies without extra components. Application: Retrofit and upgrade projects where protection logic must match system requirements. Quality note: The BRH135 is designed for reliability in demanding environments, with durable construction and long-term performance data that support maintenance budgeting and lifecycle planning across multiple facilities.
