Eaton BRH150 BR thermal magnetic circuit breaker - UL 490
Part Number: BRH150
Quick Summary
Eaton BRH150 BR thermal magnetic circuit breaker provides reliable overcurrent protection for Type BR load centers. Engineers often struggle to select the right amperage, coordinate wire sizes, and fit a plug-on device into compact panels. Key certifications include UL 490 safety approval and Federal Specifications W-C376 compliance, signaling dependable performance in code-driven installations. With HACR and shunt-trip options and a compact plug-on form, the BRH150 reduces field wiring errors and downtime. Procurement and installation efficiency rise when using a standardized BR family unit across multiple panels. This device also supports space-saving layouts and predictable maintenance, helping facility teams meet uptime targets.
Product Information
Extended Description
BRH150 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,50 A,22 kAIC,Single-pole,120/240V,BRH,#14-4 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRH150
UPC
786676373302
Product Length/Depth
3 in
Product Height
2.9 in
Product Width
1 in
Product Weight
0.3 lb
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
50 A
Voltage rating
120/240 V
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
22 kAIC
Main circuit breaker
BRH
Wire size
#14-4 AWG Cu/Al
Number of poles
Single-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - BRH150
Eaton type BR circuit breaker limited warranty June 2024
Feature: Type BR 1-Inch plug-on circuit breaker BRH150 is designed for quick, screwless installation in BR load centers. Business impact: faster retrofits, reduced miswiring risk, and streamlined panel organization. Application: ideal for residential and light-commercial distribution where spaces are tight and upgrade cycles are common. Feature: 50 A, 120/240 V single-pole configuration with a 3 in length, 2.9 in height, and 1 in width. Business impact: consistent protection for common lighting and receptacle circuits while preserving panel real estate. Application: suitable for compact panels where space efficiency drives cost savings. Feature: 22 kAIC interrupt rating provides robust fault-current handling. Business impact: enhanced safety margins in higher fault conditions; reduces risk of arcing and equipment damage. Application: critical distribution circuits in mixed loads. Feature: Wire size compatibility #14-4 AWG Cu/Al and plug-on mounting. Business impact: simplifies wiring, accelerates installation, and supports standard conductor inventories. Application: broad compatibility with BR Loadcenters. Feature: Compliance and options (HACR, shunt-trip, switching duty) increase configuration flexibility. Business impact: tailor protection to application requirements without changing hardware. Application: versatile protection across residential and light-commercial panels.
