Eaton BRH2125BP50 BR thermal magnetic circuit breaker - 22 kAIC
Part Number: BRH2125BP50
Quick Summary
The Eaton BRH2125BP50 BR thermal magnetic circuit breaker protects 120/240V distribution panels from overloads. In busy facilities, incorrect sizing and nuisance trips can trigger costly downtime and safety concerns. It carries UL 490 certification and complies with Federal Specifications W-C376, with options for HACR, shunt-trip, and high-magnetic settings to tailor protection. Designed for Type BR Loadcenters, this bulk-pack breaker reduces stocking complexity and procurement costs while simplifying field replacements. Its common-trip feature supports coordinated protection across paired circuits, improving safety margins and simplifying panel labeling. With a 125 A rating and 22 kAIC interrupt capability, it delivers reliable protection without compromising on-footprint efficiency. This model aligns with modern electrical distribution practices and supports scalable, maintainable installations.
Product Information
Extended Description
BRH2125BP50 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker bulk pack,Bulk pack,125 A,22 kAIC,Two-pole,120/240V,BRH,Common breaker trip,#4-1/0 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRH2125BP50
UPC
786685271477
Product Length/Depth
1 in
Product Height
1 in
Product Width
1 in
Product Weight
1 lb
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker bulk pack
Special features
Bulk pack
Voltage rating
120/240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Interrupt rating
22 kAIC
Main circuit breaker
BRH
Wire size
#4-1/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - BRH2125BP50
Eaton type BR circuit breaker limited warranty June 2024
Feature: 1-Inch plug-on circuit breaker, Type BR, bulk-pack design. Business Impact: Reduces panel footprint, simplifies stocking, and speeds replacements for large projects. Application: Ideal for BR Loadcenters in residential and light commercial installations. Feature: 125 A rating with 22 kAIC interrupt rating. Business Impact: Enables safe interruption of high fault currents with minimal arc suppression concerns, lowering downtime risk and improving crew safety. Application: Suitable for panels serving moderate-to-large loads in commercial buildings. Feature: Two-pole, 120/240 V operation. Business Impact: Delivers coordinated protection across both conductors, enhancing system reliability and simplifying wiring schematics. Application: Common in main distribution panels and service equipment. Feature: Wire size compatibility #4-1/0 AWG Cu/Al. Business Impact: Supports flexible wiring options and reduces the need for recompression or splicing, cutting installation time. Application: Directly supports feeder and branch circuits in BR Loadcenters. Feature: Common breaker trip and bulk-pack convenience. Business Impact: Ensures simultaneous disconnection of related circuits, improving safety coordination while lowering procurement costs through bulk orders. Application: Centralized protection in multi-circuit panels and project marine or industrial installations. Feature: Compliance and reliability—UL 490, Federal Specifications W-C376, HACR/shunt-trip options. Business Impact: Meets code and industry standards, expands protective capabilities, and supports energy management strategies. Application: Codes-compliant installations across residential, commercial, and light-industrial sites. Feature: Compatibility with Type BR Loadcenters. Business Impact: Streamlines design-in and replacement workflows, reducing engineering time and risk of mismatch. Application: Retrofit and new-build BR panel systems in distributed electrical networks.
