Eaton BRH380 BR Thermal Magnetic Circuit Breaker - UL 490
Part Number: BRH380
Quick Summary
The Eaton BRH380 BR thermal magnetic circuit breaker protects three-phase circuits in industrial panels. When panel protection is required against short circuits and overloads, this common-trip unit minimizes nuisance trips and downtime. UL 490 certification and Federal Specifications W‑C376 compliance underpin its safety and federal-installation suitability, while HACR-ready and high-magnetic options extend its applicability to motors and demanding switching duties. Designed for Type BR Loadcenters, the plug-on 1-Inch package simplifies retrofits and spare parts management. With an 80 A rating, 22 kAIC interrupt capacity, and copper/aluminum wire compatibility (#4-1/0 AWG), it delivers reliable protection in industrial automation environments and supports compliant, efficient panel design.
Product Information
Extended Description
BRH380 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,80 A,22 kAIC,Three-pole,240V,BRH,Common breaker trip,#4-1/0 AWG Cu/Al,Q28,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRH380
UPC
786676002745
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
2 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
80 A
Voltage rating
240 V - 240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
22 kAIC
Main circuit breaker
BRH
Wire size
#4-1/0 AWG Cu/Al
Number of poles
Three-pole
Quantity
28
