Eaton BRHH145 Thermal Magnetic Circuit Breaker - UL 490
Part Number: BRHH145
Quick Summary
BRHH145 is a thermal magnetic circuit breaker designed for Type BR loadcenters, delivering reliable protection for residential and light commercial panels. This unit helps minimize nuisance trips and costly downtime by offering a single, common trip for coordinated shutdown across circuits. With UL 490 listing and Federal Specifications W-C376 compliance, it meets essential safety and regulatory requirements while enabling HACR switching and high-magnetic options when needed. Its 1-Inch plug-on form factor simplifies retrofit and future upgrades, reducing panel footprint and installation time. By combining robust protection with straightforward installation, BRHH145 supports fast project delivery and a lower total cost of ownership.
Product Information
Extended Description
BRHH145 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,45 A,42 kAIC,Single-pole,120/240V,BRHH,Common breaker trip,#14-4 AWG Cu/Al,BRHH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH145
UPC
786676002813
Product Length/Depth
3 in
Product Height
3 in
Product Width
2 in
Product Weight
0.3 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
45 A
Voltage rating
120/240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BR
Wire size
#14-4 AWG Cu/Al
Number of poles
Single-pole
The 45 A rating at 120/240 V provides strong branch-circuit protection with a 42 kAIC interrupt rating, enabling fast fault clearance and reducing the risk of equipment damage and downtime in demanding panels. The 1-Inch plug-on design and single-pole configuration simplify field installation and future replacements, allowing quick upgrades in Type BR Loadcenters without excessive rewiring. A common trip across the feeder and branch circuits promotes safe, coordinated shutdowns during maintenance and fault events, enhancing safety and regulatory compliance. Wiring flexibility includes #14-4 AWG Cu/Al conductors, with a compact footprint (3 in L x 3 in H x 2 in W) and a weight of 0.3 lb, making it ideal for space-constrained installations. Compliance and warranty details (UL 490, Federal Specifications W-C376, limited lifetime residential/1-year commercial) support long-term reliability and predictable maintenance costs. Catalog notes indicate versatile availability across 10–150 A with switching duty, HACR, shunt trip, and high-magnetic settings for BR line flexibility.
Get a Quick Quote for a Eaton BRHH145
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRHH145?
Enquire Now
FAQs
Yes. BRHH145 is designed specifically for Type BR loadcenters and uses a 1-Inch plug-on mounting method. It is a single-pole device rated at 45 A with the common-trip feature, making it straightforward to install in BR family panels and retrofit existing installations without extensive rewiring.
BRHH145 provides a 45 A amperage rating, accepts 120/240 V, and offers a 42 kAIC interrupt rating. It features a common breaker trip configuration for coordinated disconnection, and its Type BR, 1-Inch plug-on design supports reliable protection in BR loadcenters.
Yes. The BR family supports HACR and switching-duty options, and BRHH145 catalog notes indicate availability with HACR and high-magnetic settings. This makes it suitable for circuits with heating, air conditioning, and refrigerant loads where HACR rating is advantageous.
BRHH145 carries UL 490 certification and Federal Specifications W-C376 compliance, ensuring regulatory acceptance for residential and light commercial use. These certifications support safety, reliability, and compatibility with industry standards.
The unit is a 1-Inch plug-on breaker suitable for BR loadcenters, mounting as a single-pole device. It accommodates #14-4 AWG Cu/Al conductors, with a compact footprint (3 in L × 3 in H × 2 in W) and weight of 0.3 lb, simplifying installation and enabling efficient panel layouts.
