Eaton BRHH155 BR Thermal Magnetic Circuit Breaker - UL 490
Part Number: BRHH155
Quick Summary
Eaton BRHH155 thermal magnetic circuit breaker protects power distribution panels in industrial and commercial installations. Designed for plug-on mounting with a common-trip design, it reduces field wiring mistakes, speeds panel upgrades, and minimizes maintenance disruption in demanding environments. UL 490 listed and Federal Specifications W-C376 compliant, the device also supports HACR, shunt-trip, and high-magnetic options to meet diverse regulatory requirements and application needs. Compact, 55 A at 120/240 V, and BR Loadcenters compatible, the BRHH155 delivers reliable protection while simplifying procurement and installation for engineering teams and maintenance crews.
Product Information
Extended Description
BRHH155 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,55 A,42 kAIC,Single-pole,120/240V,BRH,Common breaker trip,#14-3/0 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH155
UPC
786676002837
Product Length/Depth
3 in
Product Height
3 in
Product Width
2 in
Product Weight
0.3 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
55 A
Voltage rating
120/240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BRH
Wire size
#14-3/0 AWG Cu/Al
Number of poles
Single-pole
Feature: Plug-on mounting enables quick, tool-friendly installation and reduces wiring errors. Business Impact: Speeds panel upgrades and lowers installation labor. Application: Ideal for Type BR Loadcenters in new builds and retrofits. Feature: Common breaker trip provides coordinated protection across connected circuits. Business Impact: Enhances safety and simplifies coordination with other protective devices. Application: Suitable for multi-pole BR configurations in commercial panels. Feature: 55 A amperage rating and 42 kAIC interrupt capacity. Business Impact: Robust short-circuit protection with narrow fault-current tolerance. Application: Fits typical industrial feeders while meeting short-circuit requirements. Feature: 120/240 V operation for split-phase systems. Business Impact: Versatile deployment across residential-commercial panels without adapters. Application: BR Loadcenters and mixed-voltage distribution. Feature: Cu/Al wire size compatibility (#14-3/0 AWG). Business Impact: Broad wiring compatibility reduces inventory needs and installation complexity. Application: Field terminations in standard conduit and lugs. Feature: UL 490 listing and Federal Specifications W-C376 compliance plus optional HACR/shunt-trip/high-magnetic settings. Business Impact: Regulatory alignment and expanded protection options minimize compliance risk. Application: Commercial and industrial installations requiring code-approved protection.
Get a Quick Quote for a Eaton BRHH155
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRHH155?
Enquire Now
FAQs
The BRHH155 is designed for Type BR Loadcenters and uses a plug-on mounting method, enabling quick upgrades and consistent protection across standard BR panels.
The BRHH155 has a 55 A amperage rating and a 120/240 V operating voltage, suitable for split-phase residential and light commercial circuits.
BRHH155 is UL 490 listed and complies with Federal Specifications Classification W-C376; it also supports options like HACR, shunt-trip, and high-magnetic settings for broader protection needs.
Install via plug-on mounting in BR Loadcenters, terminate with #14-3/0 AWG Cu/Al conductors, and ensure the unit is part of a common-trip configuration where applicable to achieve coordinated protection.
A 42 kAIC interrupt rating indicates strong short-circuit interrupt capability, reducing the risk of excessive fault current and enhancing panel protection in high-current scenarios.
