Eaton BRHH160 Thermal Magnetic Circuit Breaker - UL 490
Part Number: BRHH160
Quick Summary
The Eaton BRHH160 thermal magnetic circuit breaker protects critical branch circuits in Type BR loadcenters. It is designed to simplify installation and deliver dependable protection in commercial and light-industrial electrical distributions. This device leverages a common-trip mechanism and a 60 A rating to minimize nuisance trips while maximizing safety. UL 490 certification, Federal Specifications W-C376, and availability of HACR or shunt-trip options provide regulatory alignment and flexible protection schemes. For procurement and maintenance teams, the BRHH160 translates into reduced inventory, faster replacements, and consistent performance across BR panel systems.
Product Information
Extended Description
BRHH160 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,60 A,42 kAIC,Single-pole,120/240V,BRH,Common breaker trip,#4-1/0 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH160
UPC
786676002844
Product Length/Depth
3 in
Product Height
3 in
Product Width
2 in
Product Weight
0.3 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
60 A
Voltage rating
120/240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BRH
Wire size
#4-1/0 AWG Cu/Al
Number of poles
Single-pole
Feature → Business Impact → Application: 60 A, 120/240 V, 42 kAIC interrupt rating, single-pole, common breaker trip; delivers robust overcurrent protection with fast response, reducing the risk of equipment damage and downtime in BR loadcenters. This translates to improved uptime in panels servicing motors and lighting loads, especially in commercial applications where reliability is critical. Application: perfect for main-distribution and branch-circuit protection in BR panels handling mixed loads; ensures coordinated protection with downstream devices. Feature → Business Impact → Application: 1-Inch plug-on mounting; simplifies field installation, reduces labor time, and minimizes miswiring risk. Application: ideal for rapid replacement in retrofit projects or new BR Loadcenter deployments, supporting modular panel design and scalable protection. Feature → Business Impact → Application: Wire size compatibility #4-1/0 AWG Cu/Al; broad conductor range supports diverse feeder configurations and easy integration with existing wiring practices. Application: suitable for feeders to motors, compressors, and lighting circuits in light industrial facilities. Feature → Business Impact → Application: Catalog Notes include 10-150A options, switching duty, HACR, shunt trip and high magnetic settings; enables tailored protection profiles without stockouts. Application: enables customized protection for varying loads within BR loadcenters and complex electrical rooms. Feature → Business Impact → Application: Warranty and compliance (Limited lifetime residential, 1 year commercial; UL 490; W-C376); provides risk reduction and regulatory confidence for service contracts and facility audits. Application: supports procurement governance and maintenance planning for compliant, long-term protection.
