Eaton BRHH3100 Thermal Magnetic Circuit Breaker - 42 kAIC
Part Number: BRHH3100
Quick Summary
The Eaton BRHH3100 thermal magnetic circuit breaker protects electrical panels in industrial distribution systems. This 1-inch Type BR device delivers reliable overcurrent protection for feeders and branch circuits in both commercial and light industrial settings. Maintenance downtime and nuisance trips are common pain points; with a common breaker trip and 42 kAIC interrupt rating, it minimizes unwelcome outages. The BR family carries UL 490 certification and Federal Specifications W‑C376 compliance, aligning with stringent safety and reliability standards. Designed for BR Loadcenters and plug‑on installations, the BRHH3100 also fits into established panel footprints, simplifying sourcing and installation. For projects needing secure protection, this unit provides a balance of performance, compatibility, and long-term value.
Product Information
Extended Description
BRHH3100 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,100 A,42 kAIC,Three-pole,240V,BRH,Common breaker trip,#4-1/0 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH3100
UPC
786676003100
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
2 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
100 A
Voltage rating
240 V - 240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BRH
Wire size
#4-1/0 AWG Cu/Al
Number of poles
Three-pole
Three-pole design with a 100 A rating and 240 V supply provides coordinated protection across all phases, reducing miscoordination and downtime. The 42 kAIC interrupt rating enables safe interruption of high fault currents, supporting motor feeders and large branch circuits in industrial environments. Plug-on mounting and a Type BR 1-Inch form factor streamline installation, cutting labor time and minimizing wiring errors in BR Loadcenters. Wire-size compatibility with #4-1/0 AWG Cu/Al simplifies panel wiring and inventory management, enabling direct connections to main lugs and bus bars. UL 490 certification and Federal Specifications W-C376 compliance help ease regulatory audits and QA checks, reinforcing risk management during commissioning. Catalog notes indicating HACR, shunt-trip, and high-magnetic settings provide flexibility for future-proofing protection against motor loads and hazardous environments.
Get a Quick Quote for a Eaton BRHH3100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRHH3100?
Enquire Now
FAQs
The BRHH3100 is a Type BR 1-Inch plug-on circuit breaker, designed for plug-on mounting in BR Loadcenters. It accepts #4-1/0 AWG Cu/Al conductors and is a three-pole device with a common trip. For best results, verify panel rating matches 100 A at 240 V and ensure space and bus stabs align with the Type BR form factor to facilitate a quick, error-free swap.
With a 100 A amperage rating and 240 V operating voltage, the BRHH3100 provides robust protection for medium-to-heavy feeders. Its 42 kAIC interrupt rating supports safe fault interruption, reducing conductor and equipment damage. The three-pole common-trip design ensures coordinated protection across all phases, which is essential for balanced load distribution in industrial panels.
Catalog notes indicate BR-series devices offer HACR, shunt-trip, and high-magnetic settings for selected amperages. While the BRHH3100 supports the BR family protections, always confirm the exact configuration with the datasheet. In practice, HACR-capable variants help reduce motor heat concerns, and high-magnetic settings improve startup protection for motor loads in manufacturing environments.
The BRHH3100 carries UL 490 certification and complies with Federal Specifications W-C376. This combination supports code-compliant panel protection, safer installation practices, and audit-ready documentation. Rigorous standards alignment helps buyers meet industry and governmental requirements while maintaining consistent protection across BR Loadcenters.
Key documents are available from Eaton, including the Specification Sheet for BRHH3100 and the limited warranty guide. The specification sheet provides electrical ratings, installation notes, and compatibility details, while the warranty document outlines coverage terms. These resources aid procurement, commissioning, and long-term maintenance planning.
