Eaton BRHH330 Thermal Magnetic Circuit Breaker - UL 490
Part Number: BRHH330
Quick Summary
The Eaton BRHH330 thermal magnetic circuit breaker protects panels and branch circuits in commercial and industrial electrical systems. Sizing, compatibility, and safe installation in dense switchgear assemblies pose real challenges for engineers. UL 490 certified, Federal Specifications W-C376 compliant, and HACR/shunt-trip options are available to meet diverse regulatory and protective needs. Designed for Type BR loadcenters with plug-on mounting, it delivers reliable protection with compact form, simplifying panel upgrades and sparing valuable enclosure space. This model supports 30 A at 240 V with a 42 kAIC interrupt rating, enabling three-pole configurations where coordinated protection and fast fault clearing are critical for equipment uptime.
Product Information
Extended Description
BRHH330 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,30 A,42 kAIC,Three-pole,240V,BRH,Common breaker trip,#14-4 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH330
UPC
786676002998
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
2 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
30 A
Voltage rating
240 V - 240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BRH
Wire size
#14-4 AWG Cu/Al
Number of poles
Three-pole
Feature → Business Impact → Application. Type BR 1-Inch plug-on circuit breaker; Three-pole configuration; 30 A at 240 V enables compact, easy-to-install protection in Type BR load centers, reducing field wiring complexity and labor while improving reliability in industrial panels. Benefit: simplifies panel assembly and serviceability; Application: used in commercial and light-industrial distribution to protect branch circuits.Feature → Business Impact → Application. 42 kAIC interrupt rating delivers robust short-circuit protection, helping sustain uptime for motors, drives, and heavy loads by limiting fault energy transfer to downstream devices. Benefit: minimizes equipment damage and downtime during faults; Application: machine control panels and distribution enclosures in demanding environments.Feature → Business Impact → Application. Wire size compatibility of #14-4 AWG Cu/Al ensures secure terminations with common conductors, supporting code-compliant terminations and reliable connections. Benefit: reduces rework and termination issues; Application: feeder and branch circuits in commercial facilities.Feature → Business Impact → Application. UL 490 certification with Federal Specifications W-C376 compliance and HACR/shunt-trip options provide procurement and regulatory alignment, enabling easier audits and standardized protection. Benefit: lowers compliance risk and expands protection settings for diverse loads; Application: regulated industries and government installations.Feature → Business Impact → Application. Catalog notes enable 10-150 A coverage, switching duty, and high-magnetic/shunt-trip variants within the BR family, offering design flexibility for future upgrades. Benefit: reduces SKU proliferation and enables seamless panel modernization; Application: engineers specifying future-proof protection in evolving facilities.
Get a Quick Quote for a Eaton BRHH330
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRHH330?
Enquire Now
FAQs
Install the BRHH330 as a plug-on, three-pole device into a compatible Type BR load center. Verify the conductor size (#14-4 AWG Cu/Al) and tighten connections to the manufacturer’s torque specs. Ensure the breaker’s amperage rating (30 A) matches the circuit design and that the unit is correctly seated to enable the common trip function and proper interrupt performance.
BRHH330 is a 30 A, 240 V thermal magnetic circuit breaker with a 42 kAIC interrupt rating. It is a three-pole, plug-on device used with Type BR Loadcenters. It carries UL 490 certification, is compatible with #14-4 AWG Cu/Al conductors, and supports a common trip configuration for coordinated protection in protection panels.
Yes. The three-pole, 30 A, 240 V BRHH330 provides robust short-circuit and overload protection appropriate for motor control panels and industrial equipment. Its 42 kAIC interrupt rating helps manage higher fault energies typical in industrial drives, and the common trip feature simplifies protection coordination across multiple circuits within a BR Loadcenter.
BRHH330 carries UL 490 certification and complies with Federal Specifications W-C376. It also supports HACR and shunt-trip options, making it suitable for regulated environments and applications requiring specific safety and control features.
The BRHH330 carries Eaton’s limited lifetime warranty for residential use and a 1-year warranty for commercial installations. For detailed terms, consult the warranty document in Eaton’s resources. Routine inspections of terminals, periodic testing, and prompt replacement after faults help maintain reliable protection and performance.
