Eaton BRHH350 Thermal Magnetic Circuit Breaker - 42 kAIC
Part Number: BRHH350
Quick Summary
BRHH350 is an Eaton thermal magnetic circuit breaker that protects BR loadcenters in commercial and light-industrial panels. Users often encounter nuisance trips and compatibility gaps when upgrading panels, which drives downtime, complicates maintenance, and raises replacement costs. UL 490 certified and Federal Specifications W-C376 compliant, this unit supports reliable common-trip protection in three-pole configurations, with a 50 A rating at 240 V. Plug-on mounting for Type BR spaces, a compact 3x3x3 in footprint, and #14-4 AWG Cu/Al wiring simplify installation and reduce field wiring errors while delivering long-term cost efficiency.
Product Information
Extended Description
BRHH350 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,50 A,42 kAIC,Three-pole,240V,BRH,Common breaker trip,#14-4 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH350
UPC
786676003049
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
2 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
50 A
Voltage rating
240 V - 240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BRH
Wire size
#14-4 AWG Cu/Al
Number of poles
Three-pole
Feature: Type BR 1-Inch plug-on circuit breaker design enables quick swap-ins and streamlined panel upgrades. Business impact: reduces field labor time by eliminating bus-bar disconnections and minimizing panel downtime during modernization projects. Application: ideal for BR Loadcenters in commercial and light-industrial environments where compact, reliable protection is required. Feature: Three-pole configuration with a 50 A rating at 240 V and common-trip operation. Business impact: ensures coordinated protection for three-phase feeders, improving startup reliability and equipment safety. Application: suits motors, HVAC equipment, and control circuits within BR Loadcenters located in manufacturing floors and data rooms. Feature: 42 kAIC interrupt rating and UL 490 certification. Business impact: tolerates high fault currents, reduces arcing, and helps comply with electrical codes and industry standards. Application: critical in commercial power distribution where fault levels can be substantial, such as service panels and distribution shelves in industrial settings. Feature: Wire-size compatibility with #14-4 AWG Cu/Al and plug-on mounting. Business impact: simplifies wiring terminations, enables neat cabinet layouts, and lowers installation time. Application: supports clean, scalable terminations in Type BR Loadcenters and new build-outs where space is constrained. Feature: Warranty and compliance alignment: UL 490 certification, Federal Specifications W-C376 compliance, and a robust field-support ecosystem. Business impact: reduces maintenance risk and lifecycle costs with documented warranty coverage and easy sourcing. Application: suitable for commercial, light-industrial, and multi-panel applications needing dependable protection and standardization.
Get a Quick Quote for a Eaton BRHH350
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRHH350?
Enquire Now
FAQs
Yes. BRHH350 is a Type BR 1-Inch plug-on circuit breaker designed for BR Loadcenters. It mounts directly onto compatible buses and accepts #14-4 AWG Cu/Al conductors. During installation, align the breaker with the buses, firmly seat it, and tighten terminals to the manufacturer’s torque specs to ensure a solid, dependable connection.
BRHH350 provides a 42 kAIC interrupt rating with a common trip for the three poles. It is rated 50 A at 240 V, protecting multi-phase circuits and reducing the risk of simultaneous faults across poles. This configuration supports coordinated protection for motors and control panels with predictable, balanced trips.
Yes. The three-pole design with a common-trip feature makes BRHH350 well-suited for three-phase 240 V systems found in commercial and light-industrial environments. It delivers reliable protection for motors, HVAC equipment, and industrial controls within BR Loadcenters, helping prevent damage from short circuits and overloads.
BRHH350 carries UL 490 certification and meets Federal Specifications W-C376. These standards ensure safety, performance, and interchangeability in electrical distribution. The product’s documented warranty and compliance framework support regulatory audits and ongoing maintenance planning for multiple-panel installations.
BRHH350 is covered by a limited lifetime residential and one-year commercial warranty. Regular maintenance should focus on verifying torque at terminations, inspecting for signs of wear, and replacing components if trips or degraded contacts occur. This warranty framework helps reduce lifecycle risk and supports budget planning for panel upgrades.
