Eaton BRHH360 Thermal Magnetic Circuit Breaker - 42 kAIC
Part Number: BRHH360
Quick Summary
Eaton BRHH360 thermal magnetic circuit breaker protects BR Loadcenters in commercial and light-industrial panels. This design helps prevent nuisance trips and protects critical equipment by providing a reliable common trip across all poles. UL 490 listing, Federal Specifications W-C376 compliance, and HACR-capable configurations give you confidence in code alignment and long-term reliability. With a 60 A rating at 240 V and a 42 kAIC interrupt capability, the BRHH360 delivers robust protection while ensuring plug-on ease and seamless compatibility with Type BR Loadcenters. Its compact 3-in cube footprint and suitable conductor range support efficient field installations in modern electrical panels.
Product Information
Extended Description
BRHH360 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on circuit breaker,60 A,42 kAIC,Three-pole,240V,BRH,Common breaker trip,#4-1/0 AWG Cu/Al,BRH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHH360
UPC
786676003063
Product Length/Depth
3 in
Product Height
3 in
Product Width
3 in
Product Weight
2 lb
Warranty
Limited lifetime residential, 1 year commercial
Compliances
Federal Specifications Classification W-C376
Certifications
UL 490
Catalog Notes
10-150A. single-, two- and three-pole, selected amperageavailable in switching duty, HACR, shunt trip and high magnetic setting
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on circuit breaker
Amperage Rating
60 A
Voltage rating
240 V - 240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
42 kAIC
Main circuit breaker
BRH
Wire size
#4-1/0 AWG Cu/Al
Number of poles
Three-pole
Feature → Business Impact → Application: Common trip across three poles reduces coordination errors and arc-flash risk, improving panel protection and safety for multi-wire branch circuits in commercial or light-industrial installations. Feature → Business Impact → Application: Type BR 1-Inch plug-on mounting simplifies retrofit and new panel builds, cutting installation time and minimizing field wiring errors in BR Loadcenters. Feature → Business Impact → Application: 60 A, 240 V rating with 42 kAIC interrupt capacity provides scalable protection for motor circuits and lighting feeders, delivering reliable performance in modest fault-current environments. Feature → Business Impact → Application: Wire size capability of #4-1/0 AWG Cu/Al supports substantial feeders common in industrial control panels, enabling versatile sourcing and fewer terminal compatibility issues. Feature → Business Impact → Application: Catalog notes indicating selectable amperage ranges and options like switching duty, HACR, shunt trip, and high magnetic settings offer installers flexibility to meet exact protection profiles and code requirements. Feature → Business Impact → Application: UL 490 listing and Federal Specifications W-C376 compliance help ensure regulatory alignment, reducing procurement risk and accelerating commissioning for standards-driven projects. Feature → Business Impact → Application: The unit’s compact dimensions and BR Loadcenter compatibility contribute to space-saving, modular panel design and easier maintenance in crowded industrial installations.
Get a Quick Quote for a Eaton BRHH360
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRHH360?
Enquire Now
FAQs
The BRHH360 is designed for Type BR Loadcenters and uses a plug-on, 1-Inch form factor. It supports three-pole configurations with a 60 A rating at 240 V and accepts wire sizes up to #4-1/0 AWG Cu/Al, making it ideal for BR Loadcenter upgrades and new panel builds.
42 kAIC is the maximum fault current the breaker can interrupt safely without sustaining damage. This provides robust protection for circuits with moderate to high short-circuit currents and helps ensure panel integrity under fault conditions in accordance with applicable codes.
Yes. The BRHH360 is a three-pole, 240 V circuit breaker with a common trip, specifically designed for three-phase BR Loadcenters and compatible panel setups requiring coordinated protection across all poles.
BRHH360 is UL 490 listed and complies with Federal Specifications W-C376. Catalog notes indicate configurations supporting HACR, shunt trip, and high-magnetic settings, enabling code-compliant protection tailored to specific applications.
The product carries a limited lifetime residential and 1-year commercial warranty. Documentation such as the Eaton specification sheet and warranty guide provide detailed coverage terms and replacement guidance for field reliability and service planning.
