Eaton BRHX290 Thermal Magnetic Circuit Breaker - 22 kAIC
Part Number: BRHX290
Quick Summary
Eaton BRHX290 thermal magnetic circuit breaker protects electrical feeders in industrial control panels and motor circuits. When downtime and nuisance trips threaten production, this device provides reliable, fast-acting protection to keep processes running and crews safe. Certifications are listed as Contact Manufacturer; verify CE, SIL, and IP ratings with Eaton to ensure compliance in your region. This model integrates smoothly with BR family devices for scalable protection in panel assemblies, and its plug-on mounting supports quick installation, improving site efficiency and reducing total cost of ownership. The 90 A rating at 120/240 V and 22 kAIC interrupt capacity deliver predictable protection for demanding applications while supporting standard maintenance practices.
Product Information
Extended Description
BRHX290 Eaton: Eaton BR thermal magnetic circuit breaker,Quicklag Type BRHX circuit breaker,90 A,22kAIC,Two-pole,120/240V,BRHX,Non-interchangeable,90,Plug-on,BRHX
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRHX290
UPC
786689041717
Product Length/Depth
3.25 in
Product Height
2 in
Product Width
3 in
Product Weight
0.9 lb
Warranty
1 year
Certifications
Contact Manufacturer
Type
Quicklag Type BRHX circuit breaker
Amperage Rating
90
Voltage rating
120/240 V
Trip Type
Non-interchangeable
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
22 kAIC
Main circuit breaker
BR
Connection
Plug-on
Number of poles
Two-pole
Trip rating
90
Feature: 90 A amperage rating at 120/240 V with two poles and plug-on mounting. Business Impact: Enables precise protection for motor feeders while reducing installation time and wiring complexity, lowering labor costs and risk of mis-wiring. Application: Industrial panels and equipment racks where 90 A loads are common and plug-on devices are preferred. Feature: 22 kAIC interrupt rating. Business Impact: Provides robust short-circuit protection, minimizing arc flash exposure and equipment damage in high-current fault conditions. Application: Power distribution feeders in manufacturing lines and critical machinery. Feature: Quicklag Type BRHX design. Business Impact: Delivers fast trip response and selective coordination, improving process uptime and safety margins. Application: Fast-acting protection for motors and control circuits in control panels. Feature: BR series compatibility with plug-on mounting. Business Impact: Streamlines installation, enables scalable protection across BR panels, and reduces commissioning time. Application: Retrofit projects and multi-breaker panel builds. Feature: Non-interchangeable trip type with BR circuit breaker family. Business Impact: Prevents incorrect device substitution, enhancing safety and compliance in maintenance programs. Application: Industrial control and safety-critical circuits. Feature: 1-year warranty. Business Impact: Provides peace of mind and predictable after-sales support, reducing lifecycle risk. Application: Field service and maintenance planning for mission-critical equipment. Long-tail keywords integrated: 90 A circuit breaker, 22 kAIC interrupt rating, 120/240 V protection, plug-on mounting, two-pole BRHX, industrial control panels, motor feeders, BR series compatibility.
