Eaton BRP12L125 Main Lug Loadcenter - UL 67/UL 50
Part Number: BRP12L125DG
Quick Summary
The Eaton BRP12L125 is a main lug loadcenter for indoor service panels in commercial and light industrial settings. This design helps mitigate field wiring errors and maintenance challenges with a robust, clearly labeled enclosure and BR 1-inch breaker compatibility. UL 67 and UL 50 certifications support enclosure integrity and electrical safety in demanding environments. With a 125 A rating, 24 circuits across 12 spaces, and a NEMA 1 metallic enclosure, it delivers reliable power distribution inside a compact footprint. The unit’s surface and flush mounting options, combined with a 10-year warranty, translate to lower lifecycle costs and faster, more predictable installations for facilities managers and installers alike.
Product Information
Extended Description
BRP12L125DG Eaton: Eaton Eaton BR main lug loadcenter,Main Lug Only,Main lug only,125 A,X0,Aluminum, NEMA 1,Metallic,10kAIC,BR,Surface,flush,NEMA 1,24 Circuits,Single-pole,12 Spaces,Two hots,a neutral and a ground,Single-phase,1,120/240V,#6-1/0 AWG Cu/Al
Product Name
Eaton BR main lug loadcenter
Catalog Number
BRP12L125DG
UPC
786689054946
Product Length/Depth
16.75 in
Product Height
3.88 in
Product Width
14.31 in
Product Weight
16.1 lb
Warranty
10 year
Certifications
UL 50 UL 67
Special features
Main Lug Only
Type
Main Lug Only
Amperage Rating
125 A
Bus material
Aluminum
Cover
Cover included
Main circuit breaker
BR
Mounting
Surface, flush
Number of circuits
24
Number Of Poles
Single-pole
Number of spaces
12
Phase
Single-phase
Used with
BR
Voltage rating
120/240V
Wire size
#6-1/0 AWG Cu/Al
Box size
X0
Enclosure
NEMA 1
Enclosure material
Metallic
Interrupt rating
10 kAIC
NEMA rating
NEMA 1
Number of wires
Two hots, neutral and ground
Quantity
1
Feature: 125 A main lug capacity and 24 circuits across 12 spaces. Business Impact: Supports mid-size indoor distribution without a full panel upgrade, enabling scalable expansion and reducing upfront capital expenditure. Application: Office buildings, light industrial facilities, and retail/commercial spaces seeking modular power distribution. Feature: Aluminum bus material. Business Impact: Lighter weight with excellent conductivity and corrosion resistance, lowering labor costs during installation and long-term maintenance. Application: Indoor panels exposed to varying environments where long-term reliability matters. Feature: NEMA 1 metallic enclosure with 10 kAIC rating. Business Impact: Provides durable protection against dust and incidental contact while meeting strict short-circuit safety requirements, reducing downtime. Application: Harsh but indoor environments requiring compliant safety performance. Feature: Surface and flush mounting support with cover included. Business Impact: Flexible installation options that speed up retrofits and minimize faceplate modifications, cutting installation time. Application: New builds and retrofit projects in ceilings, walls, or utility rooms. Feature: Compatibility with Type BR 1-inch breakers (Used with). Business Impact: Eliminates need for alternative breakers, simplifying inventory and maintenance while ensuring safe, coordinated protection. Application: Routine service upgrades and expansion in commercial electrical rooms. Feature: 120/240 V single-phase operation and #6-2/0 AWG Cu/Al wiring. Business Impact: Standardized residential/commercial power distribution with wide wire-sizing options, improving reliability and ease of sourcing. Application: Branch circuit wiring for general purpose circuits in indoor panels. Feature: 10-year warranty and UL certifications. Business Impact: Minimizes total cost of ownership through predictable performance and strong regulatory compliance. Application: Asset management programs and compliance-driven facilities management.
Get a Quick Quote for a Eaton BRP12L125DG
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRP12L125DG?
Enquire Now
FAQs
The BRP12L125 is designed for Type BR 1-inch breakers. This compatibility ensures coordinated protection across the 24 circuits and 12 spaces, simplifying stocking and maintenance. It also supports straightforward field upgrades without changing the enclosure, aiding in scalable, cost-effective panel improvements for indoor commercial applications.
Yes. The unit features a NEMA 1 metallic enclosure suitable for indoor use, with surface or flush mounting options. Its 125 A rating, 24 circuits, and 12 spaces support typical commercial loads, while the 10 kAIC interrupt rating provides robust overcurrent protection. UL 67 and UL 50 certifications further reinforce suitability for regulated environments.
The BRP12L125 carries UL 67 and UL 50 certifications. UL 67 confirms electrical enclosure integrity under fault conditions, while UL 50 addresses enclosures' construction and safety compliance. Together they reduce regulatory risk, support safer installations, and facilitate acceptance in facilities that require proven enclosure performance.
Installation benefits include a surface or flush mounting option, a cover included for quick enclosure sealing, and wiring capacity up to #6-2/0 AWG Cu/Al. The compact footprint (16.75 in L x 14.31 in W x 3.88 in H) fits tight utility spaces, while the X0 box size supports straightforward retrofit into existing rooms and cabinets.
Eaton provides a 10-year warranty on the BRP12L125, reinforcing confidence in long-term reliability. Maintenance considerations include leveraging the BR family’s standardized mounting and breaker compatibility, routine inspections of connections, and keeping spare BR 1-inch breakers on hand to minimize downtime during routine servicing or expansion.
