Eaton BRPSURGE10CS Surge Protection Device - UL 1449
Part Number: BRPSURGE10CS
Quick Summary
The Eaton BRPSURGE10CS Surge Protection Device protects electrical systems in industrial control panels, delivering reliable surge mitigation for critical equipment. For engineers and procurement teams, inconsistent surges from lightning, grid events, or switching transients can cause downtime and equipment damage. UL 1449 and cUL Certified with 50/60 Hz compatibility and a 10 kA interrupt rating underscore its reliability for L-N and L-L protection. By pairing robust protection with a compact form factor and plug-on neutral design, it simplifies installation, reduces panel depth, and supports lower total cost of ownership across industrial applications.
Product Information
Extended Description
BRPSURGE10CS Eaton: EATON TYPE BR CIRCUIT BREAKER SURGE PROTECTIVE DEVICE, TWO POLE, PLUG-ON NEUTRAL SURGE PROTECTIVE DEVICE, 10 KA, CLAMSHELL
Product Name
Eaton Type BR plug on module surge protection device
Catalog Number
BRPSURGE10CS
UPC
786689880811
Product Length/Depth
3.6 in
Product Height
2.4 in
Product Width
3.5 in
Product Weight
0.35 lb
Certifications
UL 1449 cUL Certified
Type
TYPE BR
Frequency rating
50/60 Hz
Interrupt rating
10 kAIC
Nominal Discharge Current
10 kA
Protection
L-N, L-L
Maximum continuous operating voltage
150 V L-N, 300 V L-L
Surge current
20 kA
Short-circuit rating
10 kA
Feature → Business Impact → Application: Two-pole plug-on module designed for Eaton Type BR breakers simplifies retrofits and minimizes panel depth while preserving full surge protection, reducing installation time and field wiring complexity in control panels. Application: retrofit projects and new installations in automation cabinets where space is at a premium. Feature → Business Impact → Application: 10 kA interrupt rating with 10 kA nominal discharge current and 20 kA surge current delivers robust protection for sensitive automation electronics, extending equipment life and decreasing downtime in machine and process lines. Application: motor control centers and PLC/SCADA panels. Feature → Business Impact → Application: L-N and L-L protection coverage ensures comprehensive safety for both control circuits and equipment feeders, supporting NEC-compliant protection schemes and reducing risk of transient-induced faults. Application: distributed I/O racks and panel boards. Feature → Business Impact → Application: UL 1449 and cUL Certification provide regulatory alignment and supplier confidence, streamlining audits and procurement cycles. Application: global manufacturing sites requiring certified surge protection. Feature → Business Impact → Application: Compact 3.6 in length, 2.4 in height, and 3.5 in width with a 0.35 lb weight, plus a clamshell design, enables straightforward installation in crowded panels and improves serviceability. Application: compact control cabinets and upgrades in existing installations.
Get a Quick Quote for a Eaton BRPSURGE10CS
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRPSURGE10CS?
Enquire Now
FAQs
Installation starts with powering down the panel, then removing the adjacent breaker to access the bus. The BRPSURGE10CS plugs onto the Type BR bus and wires to the protected L-N and L-L circuits. Confirm 50/60 Hz compatibility, verify the device is in the correct position for plug-on neutral operation, and re-energize to test protected circuits.
Yes, BRPSURGE10CS is rated for 50/60 Hz systems. It provides two-pole L-N and L-L surge protection with a 10 kA interrupt rating, 10 kA nominal discharge current, and a 20 kA surge current rating, helping protect sensors, relays, drives, and control electronics from transients.
The device carries UL 1449 certification and cUL recognition, signaling compliance with recognized safety standards and reliability for both North American and international markets. These certifications help satisfy regulatory requirements, support quality assurance programs, and simplify supplier qualification for engineers and procurement teams.
BRPSURGE10CS provides L-N and L-L protection with a maximum operating voltage of 150 V L-N and 300 V L-L, a 10 kA interrupt rating, and 20 kA surge current. This combination helps shield control circuits, PLCs, and motor starters from transient events, reducing the likelihood of nuisance trips and component damage.
By limiting surge-related faults, BRPSURGE10CS can lower downtime and extend the life of sensitive electronics, sensors, and drives. The compact plug-on design reduces installation time and panel modification costs, delivering lower maintenance intervals and improved overall system reliability for modern manufacturing lines.
