Eaton BRR225 BR Thermal Magnetic Circuit Breaker - UL 1699
Part Number: BRR225
Quick Summary
The Eaton BR thermal magnetic circuit breaker protects electrical systems by interrupting overcurrent in panelboards and loadcenters. In many facilities, nuisance trips or limited remote mounting options can trigger costly downtime and safety risks. This device carries UL 1699 certification, Federal Specifications W-C375 compliance, and a 10-year warranty, underscoring reliability and longevity. Compatible with Type BR Loadcenters and two-pole configurations, it supports streamlined maintenance programs and safer panel operation while delivering dependable protection for critical loads with minimal disruption.
Product Information
Extended Description
BRR225 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch latching remote circuit breaker,25 A,10 kAIC,Two-pole,120/240V,BRR,Common breaker trip,BRR,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRR225
UPC
782114858202
Product Length/Depth
6.25 in
Product Height
3.75 in
Product Width
2.25 in
Product Weight
1.4 lb
Warranty
10 year
Compliances
Federal Specifications Classification W-C375
Certifications
UL 1699
Used with
Type BR Loadcenters
Type
Type BR 1-Inch latching remote circuit breaker
Special features
Latching remote
Amperage Rating
25 A
Voltage rating
120/240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Interrupt rating
10 kAIC
Main circuit breaker
BR
Number of poles
Two-pole
Feature: 25 A, 120/240 V rating with 10 kAIC interrupt capability. Business Impact: Provides precise protection for critical circuits while tolerating short fault currents, reducing nuisance trips and extending equipment life. Application: Ideal for branch circuits within Type BR Loadcenters and industrial panels. Feature: Two-pole, common-trip design with latching remote option. Business Impact: Ensures simultaneous disconnection across both poles and enables safe remote operation during servicing. Application: Suitable for remote installations and service panels in challenging or hard-to-reach locations. Feature: 1-Inch BR form factor with compact footprint. Business Impact: Simplifies panel layout, improves clearance, and enhances compatibility with standard BR Loadcenter slots. Application: Easy replacement in existing BR-based installations without rework. Feature: Compliance and warranty foundations. Business Impact: Meets regulatory requirements (UL 1699, W-C375) and reduces lifecycle cost with a 10-year warranty. Application: Preferred choice for OEM, panel builders, and maintenance programs seeking durable protection. Feature: Latching remote capability. Business Impact: Supports remote signaling and control, enabling fast isolation and safer maintenance workflows. Application: Valuable in industrial control rooms and remote-feed configurations where quick, dependable trips are needed.
Get a Quick Quote for a Eaton BRR225
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRR225?
Enquire Now
FAQs
The BRR225 fits standard Type BR Loadcenters and uses a two-pole, common-trip design for synchronous disconnect. Connect the line and load per the panel’s wiring diagram, ensure 120/240 V supply compliance, and verify the latching remote feature is configured as required for remote signaling. Confirm the unit is properly seated and secured to avoid loose connections that could cause nuisance trips.
BRR225 is rated for 25 A with a 120/240 V supply and a 10 kAIC interrupt rating, providing strong fault current interruption for typical industrial circuits. It’s a two-pole, common-trip breaker with a Type BR form factor, ensuring coordinated protection across both conductors and minimizing selective tripping risks in protected circuits.
Yes. The BRR225 includes a latching remote feature that supports safe remote operation, making it well-suited for remote panels or installations where technicians need to control or isolate circuits without direct access to the breaker handle. It remains compatible with Type BR Loadcenters for streamlined deployment.
The BRR225 carries UL 1699 certification and complies with Federal Specifications W-C375, reflecting its suitability for regulated electrical installations. A 10-year warranty further supports long-term reliability and reduced maintenance costs.
With its UL 1699 and W-C375 compliance, durable construction, and a 10-year warranty, the BRR225 minimizes downtime and replacement cycles. Its common-trip design and compatibility with BR Loadcenters simplify stocking and replacements, improving maintenance turnaround and total cost of ownership.
