Eaton BRWH230 BR Thermal Magnetic Circuit Breaker - UL Listed
Part Number: BRWH230
Quick Summary
Eaton BRWH230 is a 30 A thermal magnetic circuit breaker for BR load centers. This compact two-pole device protects water heater circuits and other branch lines in BR panels. Engineers face space limits and trip coordination challenges, which BRWH230 mitigates with a 1-inch plug-on footprint. It features a common-trip design to simplify wiring and improve safety during maintenance. UL Listed and Federal Specifications W-C375B compliance ensure industry-standard reliability and regulatory alignment. With a 120/240 V rating and 10 kAIC interrupt capability, it withstands peak fault currents in typical residential service. This part pairs well with Type BR Loadcenters, delivering predictable installation and straightforward procurement.
Product Information
Extended Description
BRWH230 Eaton: Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on water heater circuit breaker,30 A,10 kAIC,Two-pole,120/240V,BRWH,Common breaker trip,#14-4 AWG Cu/Al,BRWH,Type BR Loadcenters
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRWH230
UPC
786676364201
Product Length/Depth
3 in
Product Height
3 in
Product Width
2 in
Product Weight
0.6 lb
Compliances
Federal Specifications Classification W-C375B
Certifications
UL Listed
Catalog Notes
Requires two 1-inch spaces
Used with
Type BR Loadcenters
Type
Type BR 1-Inch plug-on water heater circuit breaker
Special features
Used with Type BR Loadcenters
Amperage Rating
30 A
Voltage rating
120/240 V
Trip Type
Common breaker trip
Circuit breaker type
BR
Mounting Method
Plug-on
Interrupt rating
10 kAIC
Main circuit breaker
BR
Wire size
#14-4 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - BRWH230
Eaton type BR circuit breaker limited warranty June 2024
Feature: 30 A, two-pole BR thermal magnetic breaker. Business Impact: provides robust overcurrent protection with a reliable, common-trip response, reducing the risk of cascading faults and service interruptions. Application: ideal for water heater circuits and multi-wire branch loads in BR load centers. Feature: 120/240 V rating with 10 kAIC interrupt capacity. Business Impact: accommodates high fault currents without nuisance trips, increasing system reliability and uptime. Application: residential and light commercial panels facing peak fault currents. Feature: Plug-on mounting with a 1-inch width. Business Impact: saves panel real estate and simplifies installation, accelerating commissioning and reducing field labor costs. Application: Type BR Loadcenters requiring compact protection. Feature: Wire size compatibility with #14-4 AWG Cu/Al. Business Impact: expands termination options and minimizes the need for adapters, streamlining wiring practices. Application: branch circuits in BR panels with common wiring standards. Feature: Certifications and compliance (UL Listed, Federal Specifications W-C375B). Business Impact: delivers regulatory assurance and procurement confidence, simplifying audits and long-term maintenance. Application: broad adoption in residential and light commercial installations. Feature: Common breaker trip. Business Impact: ensures synchronized shutdown of related circuits, improving safety during service and maintenance. Application: water heater and shared-load configurations within BR Loadcenters.
Get a Quick Quote for a Eaton BRWH230
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRWH230?
Enquire Now
FAQs
BRWH230 is a 30 A, two-pole thermal-magnetic breaker designed for BR load centers. It protects water heater circuits and other branch circuits within BR panels, offering a common-trip feature that simplifies wiring and enhances safety during maintenance. Its 120/240 V rating suits typical residential service setups while maintaining regulatory compliance.
The common-trip design ensures both poles trip together, reducing the risk of multi-wire branch circuit faults and providing faster, coordinated shutdown during faults. This improves safety and simplifies service procedures for water heater installations that share a neutral, helping to prevent backfeed conditions and nuisance trips across related circuits.
Yes. BRWH230 lists #14-4 AWG Cu/Al as its wire size specification, enabling direct termination without adapters in BR Loadcenters. This compatibility streamlines field terminations, reduces inventory complexity, and supports compliant installations in both residential and light commercial applications.
BRWH230 is UL Listed and complies with Federal Specifications W-C375B. These certifications provide recognized safety standards and regulatory alignment for residential panels and Type BR Loadcenters, aiding audits, warranties, and procurement with confidence in product performance.
BRWH230 is a durable, UL Listed device designed for long service life in BR Loadcenters. For maintenance, verify proper installation, secure wiring terminations, and periodic inspection for signs of wear or corrosion. Replace promptly if the trip mechanism shows hesitation or if there are signs of overheating, ensuring continued protection and system reliability.
