Eaton BRX2100 Thermal-magnetic circuit breaker - 65 kAIC
Part Number: BRX2100
Quick Summary
Engineered for robust protection, the Eaton BRX2100 thermal-magnetic circuit breaker delivers reliable overcurrent protection for BR-series panels and industrial control applications. This 100 A device operates at 120/240 V with a 50–60 Hz frequency and a 65 kAIC interrupt rating, delivering strong short-circuit resilience. A common challenge engineers face is nuisance tripping or compatibility gaps with existing panels; the BRX2100’s precise thermal-magnetic trip and BR main-circuit specification help mitigate that risk. UL Listed (E7819) and Federal Specifications (W-C375) certifications reinforce compliance in regulated facilities, while straightforward wiring with #14-2/0 AWG and compact dimensions simplify installation. The result is safer protection, reduced maintenance, and faster field replacements in distribution panels and control cabinets, supporting uptime and efficiency.
Product Information
Extended Description
BRX2100 Eaton: Eaton BR thermal magnetic circuit breaker,Thermal-magnetic circuit breaker,100 A,65 kAIC,Two-pole,120/240V,BRX,#14-2/0 AWG,BRX,65 kAIC,50-60 Hz
Product Name
Eaton BR thermal magnetic circuit breaker
Catalog Number
BRX2100
UPC
786685926803
Product Length/Depth
2.48 in
Product Height
2.938 in
Product Width
2 in
Product Weight
0.76 lb
Compliances
Federal Specifications Classification W-C375
Certifications
UL Listed file E7819
Type
Thermal-magnetic circuit breaker
Amperage Rating
100 A
Voltage rating
120/240 V
Circuit breaker type
BR
Frequency rating
50-60 Hz
Capacity
65 kAIC
Interrupt rating
65 kAIC
Main circuit breaker
BR
Wire size
#14-2/0 AWG
Number of poles
Two-pole
Thermal-magnetic operation combines overload protection with fast short-circuit interruption, reducing heat buildup and minimizing nuisance trips in demanding environments. This translates to improved equipment life and safer panel operation in manufacturing lines and distribution cabinets. Used in BR-series panels, it simplifies upgrade paths for legacy installations while preserving common wiring practices. The 100 A, two-pole design supports standard distribution setups at 120/240 V, enabling straightforward integration into existing control circuits and minimizing rewiring. Its 65 kAIC interrupt rating provides higher fault current handling, reducing downtime and extending service intervals in high-demand facilities. Wiring with #14-2/0 AWG simplifies field connections and speeds panel assembly, while compact dimensions help fit tight enclosures without sacrificing access for maintenance. Certifications and compliance accompany every unit, easing procurement and audit readiness. Finally, the UL Listed and Federal Specifications alignment offers a predictable performance envelope for regulated environments, reinforcing safety and reliability in automation projects.
Get a Quick Quote for a Eaton BRX2100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton BRX2100?
Enquire Now
FAQs
The BRX2100 is a two-pole BR-type breaker rated for 100 A and accepts #14-2/0 AWG wiring. Install per Eaton’s guidelines for BR panels, ensuring proper alignment of lugs, correct insertion, and adherence to enclosure clearance. This streamlined wiring pattern simplifies field installation while maintaining safe, code-compliant distribution protection.
The BRX2100 has a 65 kAIC interrupt rating, meaning it can safely interrupt fault currents up to 65,000 A at 120/240 V. This enhances fault clearance in high-current scenarios, reduces the risk of equipment damage, and supports reliability in moderately to heavily faulted electrical systems found in industrial environments.
Ideal for electrical distribution panels, control cabinets, and automation racks, the BRX2100 integrates seamlessly with BR-series breakers and standard BR panels. Its 100 A rating and 120/240 V operation make it suitable for shop floors, process lines, and machine control circuits where compact form and consistent protection are required.
The BRX2100 is UL Listed (E7819) and complies with Federal Specifications W-C375, ensuring alignment with safety and procurement standards. These certifications simplify audits, regulatory compliance, and customer acceptance in regulated industries such as manufacturing and distribution.
Eaton provides supporting warranty documentation for BR circuit breakers, including the limited warranty applicable as of June 2024. Refer to the warranty PDF linked in product downloads for terms, coverage, and eligibility, which helps quantify lifecycle value and maintenance planning.
