Eaton C0050E3A MTE Transformer - UL Listed, 50 VA
Part Number: C0050E3A
Quick Summary
Eaton C0050E3A MTE industrial control transformer delivers isolated 120 V control power for motor starters and control circuits. Facilities often wrestle with unreliable control power from generic transformers that overheat and drive maintenance costs. UL Listed, CSA Certified, and cUL Certified along with RoHS compliance provide safety, regulatory peace of mind, and easier cross-border sourcing. With 50 VA output and 208/277 V primary at 50/60 Hz, this compact unit reduces panel footprint while delivering dependable control power for automation systems. Its epoxy-encapsulated construction and molded-in terminals minimize vibration and installation wear.
Product Information
Extended Description
C0050E3A Eaton: Eaton Type MTE industrial control transformer, pv: 208/277v, taps: none, sv: 120v, 55°c, 50 va
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C0050E3A
UPC
786680550003
Product Length/Depth
3.61 in
Product Height
3.26 in
Product Width
3 in
Product Weight
2.8 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
UL Listed CSA Certified cUL Certified
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
208/277 V
Temperature rating
55°C
Volt ampere rating
50 VA
Secondary voltage
120 V
Epoxy encapsulation and silicon steel laminations reduce core losses and temperature rise, boosting efficiency and reliability in demanding panels. This directly lowers cooling requirements and minimizes thermal stress on control circuits, extending service life in conveyor systems and packaging lines. In practice, technicians install it in control cabinets where compact form factor saves space and simplifies wiring. Compatibility with a 208/277 V primary and 120 V secondary supports widespread control circuits and relays. The 50 VA rating aligns with typical automation loads, reducing need for oversizing and saving weight and cost. Copper windings and molded-in terminals provide robust connections and vibration resistance, while the epoxy housing protects windings from dust and moisture for longer panel life. Certifications RoHS, UL Listed, CSA and cUL support global procurement and regulatory compliance. The unit’s 3.61 in L x 3.0 in W x 3.26 in H footprint and 2.8 lb weight make it easy to fit into compact enclosures and streamline installation.
Get a Quick Quote for a Eaton C0050E3A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C0050E3A?
Enquire Now
FAQs
Install in a suitable control panel with molded-in terminals accessible for wiring. The compact footprint (3.61 in L x 3.0 in W x 3.26 in H) and 2.8 lb weight simplify enclosure layout. Use appropriate clearances per panel standards and ensure 208/277 V input wiring and 120 V secondary connections are correctly rated for your loads.
Yes. It is designed for 50/60 Hz operation and features a 55°C temperature rating with a 130°C insulation system, providing a safety margin in typical industrial environments.
The transformer is UL Listed, CSA Certified, and cUL Certified, with RoHS compliance. These certifications confirm safety and regulatory alignment for North American and global deployments, streamlining procurement and reducing compliance risk.
The unit measures 3.61 inches in length, 3.00 inches in width, and 3.26 inches in height, with a weight of 2.8 pounds. These compact dimensions support easy panel integration and flexible placement within enclosures.
The epoxy encapsulated design, copper windings, and molded-in terminals improve reliability and reduce field failures, lowering maintenance costs. Its compact form factor can reduce panel size and wiring complexity, contributing to faster assembly and lower total installed cost over the transformer life.
