Eaton C0075E2A industrial control transformer - UL Listed
Part Number: C0075E2A
Quick Summary
The Eaton C0075E2A industrial control transformer delivers 75 VA of control power from 240/480 V primary. Many engineers struggle to find compact, reliable units that fit tight panels and perform in 55°C environments. Certified CSA, cUL, and UL Listed, it meets essential safety and compliance requirements for critical automation systems. RoHS compliant and epoxy encapsulated, the unit integrates smoothly with Eaton MTE hardware, reducing installation complexity and total cost of ownership. The design uses copper windings for efficient energy transfer and low core losses, supporting stable operation across multiple primary voltages. Its 3.86 in L x 3 in W x 3.26 in H footprint and 3.4 lb weight simplify panel layouts and mounting within standard enclosures.
Product Information
Extended Description
C0075E2A Eaton: Eaton Type MTE industrial control transformer, pv: 240 x 480v, 230 x 460v, 220 x 440v, taps: none, sv: 120/115/110v, 55°c, cu magnet wire, 75 va
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C0075E2A
UPC
786680422546
Product Length/Depth
3.86 in
Product Height
3.26 in
Product Width
3 in
Product Weight
3.4 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
CSA Certified cUL Certified UL Listed
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
220 x 440 V, 230 x 460 V, 240 x 480 V
Temperature rating
55°C
Volt ampere rating
75 VA
Secondary voltage
120/115/110 V
Feature: 75 VA primary-to-secondary power rating. Business Impact: Reliable control power for automation panels reduces nuisance trips and downtime. Application: Control circuits in machine tools and panel assemblies benefit from predictable voltage supply and compact form factor. Feature: Multiple primary voltages (220x440 V, 230x460 V, 240x480 V) with secondary 120/115/110 V. Business Impact: Flexible installation across 50/60 Hz networks minimizes stocking and simplifies spec alignment. Application: Suitable for mixed voltage environments in industrial automation and process control. Feature: Copper windings and 55°C insulation system. Business Impact: Higher efficiency, reduced heat, and longer service life in hot plants. Application: Harsh production floors and energized control cabinets. Feature: Epoxy encapsulation with molded-in terminals. Business Impact: Enhanced durability against vibration and moisture, easier field wiring. Application: Rugged installations with frequent panel access. Feature: RoHS compliant with CSA, cUL, UL Listed certifications. Business Impact: Regulatory compliance and safer integration into regulated facilities. Application: Projects with strict safety and environmental requirements across automation systems. Feature: Compact footprint (3.86 in × 3 in × 3.26 in) and light weight (3.4 lb). Business Impact: Simplified panel layout, faster installation, reduced enclosure space. Application: Enclosures and control panels with tight clearances and limited mounting depth. Feature: Molded-in terminals and epoxy encapsulation. Business Impact: Lower maintenance due to vibration resistance and durable connections. Application: Heavy-duty industrial environments with frequent wiring and re-wiring needs.
Get a Quick Quote for a Eaton C0075E2A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C0075E2A?
Enquire Now
FAQs
The C0075E2A supports 220x440 V, 230x460 V, and 240x480 V primary configurations with a 120/115/110 V secondary, designed for 50/60 Hz service. It uses copper windings and epoxy encapsulation, with molded-in terminals to resist vibration. This makes it compatible with standard industrial panels and Eaton MTE installations, provided you maintain proper clearance and ventilation.
The transformer employs copper windings and an epoxy encapsulated core on silicon steel laminations, delivering lower copper losses and improved efficiency in control circuits. A 55°C insulation system and molded-in terminals enhance reliability in heat and vibration environments. As a result, you can expect consistent voltage regulation, reduced heat buildup, and extended service life in automated machinery.
Yes. The C0075E2A carries RoHS compliance along with CSA, cUL, and UL Listed certifications, ensuring regulatory alignment for critical automation installations. RoHS reduces hazardous substances, while the listed certifications confirm safe integration with electrical codes and panel assemblies. This provides traceability and confidence for safety audits and ongoing maintenance programs.
The transformer has a compact footprint of 3.86 inches in length, 3 inches in width, and 3.26 inches in height, with a weight of 3.4 pounds. Molded-in terminals and epoxy encapsulation support vibration resistance, simplifying mounting inside standard control enclosures. Plan for modest clearance around the unit to ensure adequate heat dissipation and service access.
Eaton provides a warranty per policy 25-000: one year from installation or 18 months from shipment, whichever occurs first. Availability is typically robust with datasheets and CAD resources readily accessible, supporting fast procurement cycles and predictable spare part planning. This translates to reduced downtime and more reliable maintenance planning for automation projects.
