Eaton C0150E2A Industrial Control Transformer - UL Listed
Part Number: C0150E2A
Quick Summary
Eaton Type MTE industrial control transformer provides reliable low-voltage power for control circuits in harsh industrial environments. Engineers often contend with space constraints and energy losses that drive overheating and unplanned downtime. This model carries UL Listed, CSA Certified, and cUL Certified marks, plus RoHS compliance to meet widespread regulatory requirements. With epoxy encapsulation and molded-in terminals, installation is straightforward in compact control panels, while silicon-steel laminations minimize core losses. The result is improved reliability, reduced maintenance, and a lower total cost of ownership for automation systems in manufacturing, packaging, and process industries.
Product Information
Extended Description
C0150E2A Eaton: Eaton Type MTE industrial control transformer, Eaton Type MTE industrial control transformer, pv: 240 x 480v, 230 x 460v, 220 x 440v, taps: none, sv: 120/115/110v, 55°c, 150 va , cu magnet wire
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C0150E2A
UPC
786680422584
Product Length/Depth
3.88 in
Product Height
3.74 in
Product Width
3.75 in
Product Weight
5.3 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
UL Listed CSA Certified cUL Certified
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
220 x 440 V, 230 x 460 V, 240 x 480 V
Temperature rating
55°C
Volt ampere rating
150 VA
Secondary voltage
120/115/110 V
Feature: Epoxy-encapsulated, molded-in terminal construction → Business Impact: Enhances durability and vibration resistance while saving panel space → Application: Ideal for rugged control panels in automation lines. Feature: Primary voltages 220/440 V, 230/460 V, 240/480 V with secondary 120/115/110 V and a 150 VA rating → Business Impact: Enables universal compatibility and consistent control power across machines without multiple units → Application: Used to supply 120 V control circuits from diverse supply rails in manufacturing environments. Feature: Copper windings with silicon steel laminations → Business Impact: Improves efficiency and reduces core losses, supporting reliable operation at elevated ambient temperatures → Application: Suitable for continuous-duty control power in conveyors and process equipment. Feature: 50/60 Hz operation, 55°C rating, 130°C insulation system → Business Impact: Delivers dependable performance in standard industrial power environments while resisting heat buildup → Application: Compatible with common industrial control systems and panel installations. Feature: Certifications and warranty (UL Listed, CSA, cUL, RoHS) with a one-year to 18-month warranty window → Business Impact: Simplifies regulatory compliance and reduces long-term ownership risk → Application: Fits validated procurement specs for OEMs and maintenance teams.
Get a Quick Quote for a Eaton C0150E2A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C0150E2A?
Enquire Now
FAQs
Install in a suitable control panel using molded-in terminals with adequate clearance for 3.88 in L, 3.74 in H, and 3.75 in W. Ensure ventilation and meet the 55°C operating rating; weight is 5.3 lb, and the epoxy encapsulation provides vibration resistance suitable for machinery and conveyors.
Primary voltages are 220/440 V, 230/460 V, and 240/480 V. Secondary voltage is 120/115/110 V, and the volt-ampere rating is 150 VA, making it suitable for compact control power in automation panels.
Yes, it supports 50/60 Hz operation. It uses a 130°C insulation system with a 55°C temperature rating, and copper windings for reliable, efficient performance in typical industrial environments.
The unit is UL Listed, CSA Certified, and cUL Certified, with RoHS compliance. These certifications simplify regulatory approvals, supplier qualification, and end-customer acceptance across industries.
Warranty terms follow Eaton policy 25-000: one year from installation or eighteen months from shipment, whichever occurs first. This reduces risk and supports maintenance planning for OEMs and service teams.
