Eaton C0150E3A Industrial Control Transformer - UL Listed
Part Number: C0150E3A
Quick Summary
Industrial control transformer Eaton C0150E3A delivers reliable control power from 208/277 V to 120 V for machine panels and control circuits. Engineers and procurement teams often struggle with bulky footprints, core losses, and durability in demanding environments. This model is RoHS compliant and carries cUL Listed, UL Listed, and CSA certifications to support safety and regulatory adherence. Its compact form, epoxy encapsulation, and molded-in terminals simplify installation while reducing wiring errors and lifecycle costs for panel builders. Designed for 50/60 Hz operation and 130°C insulation, it integrates smoothly with standard electrical assemblies in industrial settings.
Product Information
Extended Description
C0150E3A Eaton: Eaton Type MTE industrial control transformer, pv: 208/277v, taps: none, sv: 120v, 55°c, 150 va
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C0150E3A
UPC
786680550157
Product Length/Depth
3.88 in
Product Height
3.74 in
Product Width
3.75 in
Product Weight
5.5 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
cUL Certified UL Listed CSA Certified
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
208/277 V
Temperature rating
55°C
Volt ampere rating
150 VA
Secondary voltage
120 V
Feature: 208/277 V primary and 120 V secondary with a 150 VA rating. Business Impact: Provides sufficient control power for typical panel circuits while keeping heat and energy losses low, improving overall panel efficiency. Application: Suitable for machine control panels in conveyors, pumps, and process equipment. Feature: Copper windings and epoxy encapsulation. Business Impact: Enhances thermal performance and durability in harsh environments, reducing maintenance and replacement costs. Application: Environments with vibration, dust, and temperature fluctuations. Feature: Molded-in terminals and no taps. Business Impact: Simplifies wiring, reduces field wiring errors, and speeds installation, lowering installation time and risk of miswiring. Application: Factory automation and process control cabinets. Feature: RoHS compliance and certifications (cUL, UL Listed, CSA). Business Impact: Supports regulatory compliance and safety audits, accelerating procurement cycles. Application: Any regulated industrial setting requiring traceable certifications. Feature: 130°C insulation system and 50/60 Hz operation. Business Impact: Broadens compatibility with standard electrical systems while maintaining insulation margins at elevated ambient temperatures. Application: Industrial panels operating across diverse climates. Feature: Compact footprint (approximately 3.88 in L x 3.74 in H x 3.75 in W) and 5.5 lb weight. Business Impact: Facilitates dense enclosure layouts and easier mounting, improving panel density and serviceability. Application: Space-constrained control panels in packaging, material handling, and automation lines.
Get a Quick Quote for a Eaton C0150E3A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C0150E3A?
Enquire Now
FAQs
The C0150E3A is designed for 208/277 V primary voltage and 120 V secondary loads, delivering 150 VA for control circuits. It supports 50/60 Hz operation and is suitable for standard control panels and automation equipment. With no taps, wiring remains straightforward, reducing field wiring errors and installation time in machine control cabinets.
The transformer provides a 150 VA rating and a 55°C temperature rating, with a 130°C insulation system. This combination supports reliable operation in typical industrial panel environments while maintaining a comfortable thermal profile under continuous control loads.
Yes, the C0150E3A is RoHS compliant. It carries cUL Certified, UL Listed, and CSA Certified marks, providing assurance for safety compliance, regulatory audits, and acceptance in various jurisdictions, which helps streamline procurement and reduce risk in regulated industries.
Molded-in terminals are durable and shielded from vibration, reducing field wiring failures and loosening connections. This design speeds initial installation and simplifies future maintenance by keeping connections secured and organized inside the enclosure, which is especially beneficial in high-vibration applications like conveyors and industrial robots.
A typical use case is powering control circuits in a compact panel for automated equipment in packaging or material handling. Benefits include reduced installation time due to molded-in terminals, lower maintenance costs from durable epoxy encapsulation, and regulatory peace of mind thanks to RoHS and major certifications, contributing to a favorable total cost of ownership over the equipment lifecycle.
