Eaton C0150E5E Industrial Control Transformer - RoHS
Part Number: C0150E5E
Quick Summary
The Eaton Type MTE industrial control transformer provides reliable low-voltage power for control circuits in machine panels. In the field, inconsistent voltages and fragile terminations can drive downtime and wiring errors. This unit is RoHS compliant and UL/cUL listed with CSA certification, offering safer integration in regulated facilities. Its epoxy encapsulation, molded-in terminals, and 150 VA rating help partners reduce panel space, simplify wiring, and improve reliability across 50/60 Hz applications. Designed for 50/60 Hz operation, the transformer uses copper windings and a 130°C insulation system. Molded-in terminals plus epoxy encapsulation maximize durability in vibration and harsh environments. These features translate to fewer field calls, faster startups, and longer service life.
Product Information
Extended Description
C0150E5E Eaton: Eaton Type MTE industrial control transformer, pv: 200/220/440v, 208/230/460v, 240/480v, taps: none, sv: 23/110v, 24/115v, 25/120v, 55°c, 150 va
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C0150E5E
UPC
786680420368
Product Length/Depth
3.75 in
Product Height
3.63 in
Product Width
3.96 in
Product Weight
7.9 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
CSA Certified UL Listed cUL Certified
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
200/220/440 V, 208/230/460 V, 240/480 V
Temperature rating
55°C
Volt ampere rating
150 VA
Secondary voltage
23/110 V, 24/115 V, 25/120 V
Epoxy encapsulation with molded-in terminals reduces exposure to moisture and vibration, delivering durable, field-ready performance. Business impact: fewer wiring faults, longer-lasting terminations, and lower maintenance costs. Application: machine control panels and panel builders seeking rugged, drop-in replacements for legacy transformers. Copper windings on a laminated silicon-steel core deliver efficient energy transfer and minimized core losses. Business impact: cooler operation, improved reliability, and energy savings in continuous-duty control circuits. Application: relays, timers, PLC power rails in automation cabinets. Broad primary voltages and flexible secondary options—200/220/440 V and 208/230/460 V inputs; secondaries 23/110, 24/115, 25/120 V—enable universal compatibility. Business impact: reduces SKU proliferation and speeds procurement. Application: OEMs with global deployments and multi-site installations. Compact footprint with 3.75 x 3.96 x 3.63 in dimensions and 150 VA rating fits tight control panels. Business impact: lower enclosure footprint, easier cooling, and simplified service access. Application: PLC power rails and relay banks in compact machines. Regulatory compliance and a strong warranty posture further reduce risk: RoHS, CSA, UL/cUL, epoxy encapsulation, molded terminals, plus a one-year warranty from installation or 18 months from shipment. Application: procurement teams seeking compliant, reliable power for critical control circuits.
Get a Quick Quote for a Eaton C0150E5E
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C0150E5E?
Enquire Now
FAQs
Begin by mounting the unit securely in a fanless, ventilated area. Connect the primary to the appropriate voltage set (200/220/440 V or 208/230/460 V or 240/480 V) using the molded-in terminals, then connect the control-side devices to one of the secondary voltages (23/110, 24/115, or 25/120 V). Verify insulation and ensure all protective devices are correctly rated for 150 VA. Finally, perform a voltage check with the system powered to confirm correct operation.
Primary voltages include 200/220/440 V, 208/230/460 V, and 240/480 V. Secondary voltages offered are 23/110 V, 24/115 V, and 25/120 V. The transformer is compatible with 50/60 Hz operation and features a 130°C insulation system, ensuring compatibility with typical industrial control circuits and panel layouts.
Yes. With a 150 VA rating and flexible secondary voltages, the C0150E5E is well-suited to power PLCs, relays, and other control circuits within compact panels. Its copper windings and robust construction support reliable, steady control power, while molded-in terminals simplify wiring and reduce field failures in vibration-prone environments.
The transformer is RoHS compliant and UL/cUL listed, with CSA certification. These certifications support safe integration in regulated facilities and simplify supplier qualification, audits, and long-term maintenance across North American operations.
The C0150E5E comes with Eaton's warranty policy: one year from the date of installation or eighteen months from the date of shipment, whichever occurs first. This provides protection against manufacturing defects and reduces total cost of ownership during the device’s initial service life.
